2.1
Introduction
The following sections show the internal jumper settings and external connector pin
assignments for application integration.
2.2
System Status Indicators
2.2.1
System Status LEDs
The top right LED on the front panel indicates the system health and active status.
Refer to the table below for a LED function description.
Item
LED
1
PWR/FAULT
2
HDD
ITA-3650T Series User Manual
Figure 2.1 ITA-3650 LED
Status
Color
Description
On
Green
System power is on, system is safe
On
Red
System voltage overheated
On
Data being received/transmitted
Yellow
Off
No data being received/transmitted
8
HDD Indicator
Power/Alarm Indicator
