2.4.1

COM Connectors

ITA-3650T features up to two D-sub 9-pin connectors for RS-232/422/485.
Pin
1
2
3
4
5
6
7
8
9
2.4.2

USB Connector

ITA-3650T is equipped with a serial USB 3.0 port and connector. They can be disa-
bled in the system BIOS menu.
Pin
1
2
3
4
RS-232 RS-422
Signal Name Signal Name
DCD Tx-
RxD Tx+
TxD Rx+
DTR Rx-
GND GND
DSR NC
RTS NC
CTS NC
RI NC
Signal Name
+V5(VCC)
USB_data-
USB_data+
GND
15
RS-485
Signal Name
DATA-
DATA+
NC
NC
GND
NC
NC
NC
NC
