1.1

Introduction

The UNO-1372G is an embedded Application Ready Platform (ARP) that can
shorten development time and offers multiple networking interfaces to fulfill the
extensive needs of different projects.
The UNO-1372G includes Intel's latest Intel Atom technology and provides multiple
interfaces, including up to two serial ports, three GbE LAN and three USB ports.
The UNO-1372G supports two display types, HDMI and VGA, for various high resolu-
tion requirements.
The UNO-1372G can operate in a wide temperature range (from -20 to 60° C).
The UNO-1372G adopts Intel Atom CPU with Quad-Core computing power and up to
4GB DDR3 (supports a max of 8GB) of built-in RAM for multi-tasking programs.
The UNO-1372G provides great expansion including two Mini PCIe and SIM card
support. These expansions, plus iDoor technology, ensures that the UNO-1372G has
great expandability from Wi-Fi, 3G, I/O expansion and fieldbus card with iDoor tech-
nology.
With a wide array of OS and driver support, such as Windows 7/8, WES7/WE8S, and
embedded Linux, users can integrate applications easily in an application ready plat-
form that provides versatile functionality to fulfill diverse requirements.
1.2

Safety Precautions

The following sections explain how to make each connection. In most cases, you will
simply need to connect a standard cable.
Note! Safety Certification Temperature 50° C(122° F)
Warning! Always disconnect the power cord from your chassis whenever you are
working on it. Do not connect while the power is on. A sudden rush of
power can damage sensitive electronic components. Only experienced
electronics personnel should open the chassis.
Warning! Toujours débrancher le cordon d'alimentation de votre boîtier lorsque
vous êtes travailler. Ne branchez pas lorsque l'appareil est allumé. Un
afflux soudain de puissance peut endommager les composants électro-
niques sensibles. Seulement connu personnel de l'électronique
devraient ouvrir le châssis.
Caution! Always ground yourself to remove any static electric charge before
touching the product. Modern electronic devices are very sensitive to
static electric charges. Use a grounding wrist strap at all times. Place all
electronic components on a static-dissipative surface or in a static-
shielded bag.
