Enclosure/Backplane Mounting Instructions; Installation Instructions - Altronix NetWaySP8WP2 Series Installation Manual

Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes
and authorities having jurisdiction. All units should be installed by a trained service personnel.
NetWaySP8WP2/NetWaySP8WPX2 Enclosure Mounting and Installation:
1. Remove backplane from enclosure prior to drilling. Do not discard hardware.
Note: Make sure that hardware will not interfere with components of the circuit board.
2. Mark and drill desired inlets on the enclosure to facilitate wiring. Maximum NEMA type 4X rated fittings to
be used are 0.5". Follow manufacturer's specifications for the appropriate size opening.
Note: Inlets for conduit fittings should only be made on the bottom of the enclosure.
UL Listed NEMA type 4X rated conduit connector/hubs shall be used for the appropriate size inlets.
3. Clean out the inside of enclosure before remounting circuit board.
4. Mounting NEMA4/4X rated enclosure (Enclosure Dimensions, pgs. 12-15):
Wall mount: Mount unit in desired location. Mark and drill holes to line up with the top and bottom holes of
the enclosure flange. Secure enclosure with appropriate fasteners (e. g. screws and anchors;
bolts and locking nuts, etc.) that are compatible with mounting surface and are of sufficient
length/construction to ensure a secure mount (Fig. 5, pg. 11).
Pole Mount: Refer to Figs. 8 - 13, pg. 11.
5. Mount backplane in enclosure with hardware.
6. To facilitate wire entry utilize weather-tight NEMA rated connectors (supplied), bushings, and cable.
NetWaySP8X2 Enclosure Mounting and Installation:
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure. Install two (2) upper fasteners and screws in the wall with the screw heads protruding.
Place the enclosure's upper keyholes over the two (2) upper screws; level and secure. Mark the position of
the lower two (2) holes. Remove the enclosure. Drill the lower holes and install two fasteners. Place the
enclosure's upper keyholes over the two (2) upper screws. Install the two (2) lower screws and make sure to
tighten all screws (Enclosure Dimensions, pg. 12). Secure enclosure to earth ground.
NetWaySP8PL2 Mounting and Installation:
1. Mount backplane in the desired location/enclosure with hardware supplied.
1. Secure cabinet to earth ground. Connect AC power from overcurrent protective device circuit breaker
(20A @ 115VAC, 60Hz, 16A @ 230VAC, 50/60Hz) to the terminals marked [L, N] on power supply board
(Fig. 4, pg. 10). Use 14AWG or larger for all power connections (Battery, DC output, AC input).
Connect ground lug to earth or green branch wire (12AWG min.).
Keep power-limited wiring separate from non power-limited wiring by utilizing separate knockouts/
inlets. Minimum 0.25" spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing
equipment. There are no user serviceable parts inside.
Refer installation and servicing to qualified service personnel.
2. Port Configurations (Fig. 1, pg. 4; Fig. 4a, pg. 10):
Jumper
Jumper Position
PORT 4 30W
PORT 6 30W
PORT 4 60W
PORT 6 60W
- 4 -
Enclosure Mounting Instructions:

Installation Instructions:

1 2 3
30W and Data
––––
Data Only
––––
Structured Cable Ports
4
60W and Data
Data Only
5 6
––––
30W and Data
––––
60W and Data
PORT 2
30W 60W
NetWaySP82 Series Installation Guide
7 8
Data Only
Fig. 1
