Typical VLan Setup:
Fig. 3
Example
Example
vLan ID 20
vLan ID 10
for ports 5-6
for ports 1-4
Pass thru
Trunk
(i.e. VLan ID 10 and/or 20)
(i.e. VLan ID 10 and 20)
Fiber to
Fiber from
Next NetWaySP82
Host Switch
NetWaySP82 Series Installation Guide
