Mechanical Drawing and Dimensions (H x W x D approx.):
1.20"
(30.5mm)
1.40"
(35.6mm)
3.25" (82.6mm)
1.0" (25.4mm)
- 12 -
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm)
1.40"
4.85" (123.2mm)
(35.6mm)
0.75"
(19.1mm)
1.0"
(25.4mm)
NetWaySP8X2
4.85" (123.2mm)
12.5" (317.5mm)
11.0" (279.4mm)
10.5" (266.7mm)
1.40"
(35.6mm)
1.20"
(30.5mm)
0.75"
(19.1mm)
0.9375" (23.8mm)
0.9375" (23.8mm)
3.25" (82.6mm)
1.0"
(25.4mm)
NetWaySP82 Series Installation Guide
1.20"
(30.5mm)
1.40"
(35.6mm)
