2.3 Electric Installation

This subsection describes how to install the modules, how to connect the 2N
Verso main unit to the power supply and LAN and how to connect other elements.
Caution
The device must be part of the electrical system of the building.
Mounting Preparation
Unscrew the second module cover on the main unit base.
1.
Use a flat screwdriver to take out the module cover.
2.
Version A – 2-Module Base
Place the base on the flush mounting box / predrilled holes with dowels and pull
1.
the cables through the bottom holes. Pull the Ethernet cable including the
connector through the bottom hole to the left if necessary.
Insert the metal fitting elements up and down and screw the base plate tight.
2.
You can level the base slightly if you are mounting just one base.
Version B – 3-Module Base
Unscrew the cover of the additional base.
1.
Use a flat screwdriver to take out the cover.
2.
Slide the additional base to the main unit base and secure its position with the
3.
small side wedges and screws.
Remove the microphone from the main unit base and loosen the microphone
4.
cable.
Lead the microphone to the third module base as shown in the figure.
5.
Place the joined bases on the flush mounting box / predrilled holes with dowels
6.
and pull the cables through the bottom holes. Feed the Ethernet cable without
the connector from the additional base to the main unit base if necessary.
