AXIS I8016-LVE Network Video Intercom
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I8016-LVE and is the answer not in the manual?

Questions and answers

Related Manuals for Axis I8016-LVE

Summary of Contents for Axis I8016-LVE

  • Page 1 AXIS I8016-LVE Network Video Intercom User Manual...

  • Page 2: Table Of Contents

    AXIS I8016-LVE Network Video Intercom Table of Contents Setup overview ..........

  • Page 3: Setup Overview

    AXIS I8016-LVE Network Video Intercom Setup overview Setup overview Intercom Intercom combined with AXIS A9801 Intercom combined with AXIS A9161 Intercom combined with a reader and an access control system, for example AXIS A1001 or AXIS A1601...

  • Page 4: Product Overview

    AXIS I8016-LVE Network Video Intercom Product overview Product overview Call indicator icons on page 22 Camera Call button IR illuminator Speaker Microphone I/O connector on page 23 Control button on page 22 10 Status LED 11 SD card slot on page 22 (microSD/microSDHC/microSDXC)

  • Page 5: Get Started

    Get started Find the device on the network To find Axis devices on the network and assign them IP addresses in Windows®, use AXIS IP Utility or AXIS Device Manager. Both applications are free and can be downloaded from axis.com/support.
  • Page 6 Secure passwords Important Axis devices send the initially set password in clear text over the network. To protect your device after the first login, set up a secure and encrypted HTTPS connection and then change the password. The device password is the primary protection for your data and services. Axis devices do not impose a password policy as they may be used in various types of installations.

  • Page 7: Additional Settings

    AXIS I8016-LVE Network Video Intercom Additional settings Additional settings This section will cover all the important configurations that an installer needs to do to get the product up and running after the hardware installation has been completed. Change the root password 1.

  • Page 8: Set Up Sip Through A Server (Pbx)

    AXIS I8016-LVE Network Video Intercom Additional settings Set up SIP through a server (PBX) VoIP (Voice over IP) is a group of technologies that enables voice and multimedia communication over IP networks. For more, see Voice over IP (VoIP) on page 12.

  • Page 9: Configure The Call Button

    By default, the call button is configured to make VMS (Video Management System) calls. If you want to keep this configuration, you just need to add the Axis intercom to the VMS. This example explains how to set up the system to call a contact in the phone book when a visitor presses the call button.

  • Page 10: Use Dtmf To Unlock The Door For A Visitor

    In the Name field, enter "DTMF unlock door". From the list of triggers, select Call, DTMF and Unlock door. From the list of actions, select Axis Door Control. 5. Click New Recipient. 6. Enter the details for the door controller and click OK.

  • Page 11: Print A Contact List

    AXIS I8016-LVE Network Video Intercom Additional settings From the list of triggers, select Call, DTMF and Unlock door. From the list of actions, select Output Port. 6. From the list of ports, select Relay 1 (Port 4). 7. Select Duration.

  • Page 12: Learn More

    In the Axis product, VoIP is enabled through the Session Initiation Protocol (SIP) and Dual-Tone Multi-Frequency (DTMF) signaling. Example When you press the call button on an Axis intercom, a call is initiated to one or more predefined recipients. When a recipient replies, a call is established. The voice and video is transferred through VoIP technologies.
  • Page 13 User agent A - intercom. SIP address: sip:192.168.1.101 User agent B - SIP-enabled phone. SIP address: sip:192.168.1.100 You can set up the Axis intercom to call for example a SIP-enabled phone on the same network using a peer-to-peer SIP setup. Private Branch Exchange (PBX) When you make SIP calls outside your local IP network, a Private Branch Exchange (PBX) can act as a central hub.

  • Page 14: Set Up Rules And Alerts

    PBX sip.company.com sip:office@company.com When you press the call button on an Axis intercom, the call is forwarded through one or more PBXs to a SIP address either on the local IP network or over the internet. Set up rules and alerts You can create rules to make your device perform an action when certain events occur.

  • Page 15: Troubleshooting

    To find the latest firmware and the release notes, go to axis.com/support/firmware 1. Download the latest firmware file to your computer, available free of charge at axis.com/support/firmware 2. Log in to the device as an administrator.

  • Page 16: Technical Issues, Clues And Solutions

    Axis device. Check all cabling and reinstall the device. Possible IP address conflict The static IP address in the Axis device is used before the DHCP server sets a dynamic address. with another device on the...
  • Page 17 Heavy network utilization due to poor infrastructure affects the bandwidth. • Viewing on poorly performing client computers lowers perceived performance and affects frame rate. • Running multiple AXIS Camera Application Platform (ACAP) applications simultaneously may affect the frame rate and the general performance.

  • Page 18: Connect Equipment

    AXIS I8016-LVE Network Video Intercom Connect equipment Connect equipment Relay powered by PoE (12V) Wiring diagram Configuration 1. To check relay state, go to Hardware > I/O ports > Relays. 2. Click Edit. 3. Depending on your lock type, set Normal state to:...

  • Page 19: Potential-Free Relay

    AXIS I8016-LVE Network Video Intercom Connect equipment Configuration 1. To check relay state, go to Hardware > I/O ports > Relays. 2. Click Edit. 3. Depending on your lock type, set Normal state to: Open circuit for a fail-secure lock Closed circuit for a fail-safe lock 4.

  • Page 20: 12V Fail-Secure Lock Powered By Poe From Intercom

    AXIS I8016-LVE Network Video Intercom Connect equipment 12V Fail-secure lock powered by PoE from intercom Wiring diagram Configuration 1. To check relay state, go to Hardware > I/O ports > Relays. 2. Click Edit. 3. Depending on your lock type, set Normal state to:...
  • Page 21 AXIS I8016-LVE Network Video Intercom Connect equipment Configuration 1. To check relay state, go to Hardware > I/O ports > Relays. 2. Click Edit. 3. Depending on your lock type, set Normal state to: Open circuit for a fail-secure lock Closed circuit for a fail-safe lock 4.

  • Page 22: Specifications

    AXIS I8016-LVE Network Video Intercom Specifications Specifications Front panel indicators and controls When you connect the product to power, the indicator icons and the indicator strip light up for xx seconds. Call indicator icons Icon Indication Steady amber when outgoing call initiated.

  • Page 23: Connectors

    AXIS I8016-LVE Network Video Intercom Specifications Connectors Network connector RJ45 Ethernet connector with Power over Ethernet (PoE). Audio connector 4-pin terminal block for audio input and output. Function Notes Line in Line in (mono) Audio ground Line out Line out (mono)

  • Page 24: Hazard Levels

    AXIS I8016-LVE Network Video Intercom Safety information Safety information Hazard levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 25 User Manual Ver. M2.3 AXIS I8016-LVE Network Video Intercom Date: March 2021 © Axis Communications AB, 2020 - 2021 Part No. T10154915...
