Caution
The area where nametags are placed is called a wet zone. After heavy
rain, water can penetrate to the nametag. Water in this area does not
affect the intercom functionality in any way and evaporates soon.
Always use waterproof foil (enclosed or other) for the nametags. Never
use paper or ink jet printing to avoid damage due to water leakage!
Nametag inserting/replacing:
Remove the frame.
1.
Lift up the button door. The 5-button module buttons have just one door.
2.
Remove the used nametag and insert a new one.
3.
Close the button door.
4.
Replace the frame.
5.
Frame Replacement
Check the frame sealing before replacing the frame.
Version A
Screw the flush mounting frame in the upper and bottom parts.
Version B
Hang the surface mounting frame on the hook in the upper part and then screw
it tight in the bottom part.
Caution
Improper mounting may deteriorate the intercom waterproofness and
water may damage the electronic part.
Make sure that all holes are filled with some waterproof material – the
top part, around the cables and the screws.
Use silicone or some other sealant to seal the box against the wall if
uneven to avoid water leakage and wall damping..
