Wiegand

The Wiegand (Part No. 9155037) is one of the
used for connecting an external Wiegand device (RFID card reader, fingerprint or
other biometric data reader) and/or connecting the
external security exchange. All the inputs and outputs are galvanically isolated from
®
the 2N IP Verso system with insulation strength of 500 V DC. It is necessary to feed
+U IN on Wiegand OUT from the Control Panel.
Reader – connects an external Wiegand-supporting reader. The reader sends
information on the intercom card number.
Control Panel – used for connection to the security PBX or access system to
which the intercom sends information on the intercom card number.
The module contains two
These two connectors are fully interchangeable and can be used both as inputs
from the main unit and outputs to other modules.
If this module is the last one on the bus, one of the connectors remains
unconnected.
The module package includes an 80 mm long interconnecting cable.
The module name is configured in the Module name parameter in the Hardware /
Extenders menu.
The input LED IN is addressed as follows:
module2.input1.
The input Tamper is addressed as follows:
module2.tamper.
The output LED OUT (negated) is addressed as follows: <module_name>.
<output1>
2N TELEKOMUNIKACE a.s., www.2n.cz
®
2N IP Verso
, e.g. module2.output1.
®
2N IP Verso intercom elements and is
®
2N IP Verso
bus connectors.
<module_name>.<input1>
<module_name>.<tamper>
system to an
, e.g.
, e.g.
