Version C – Additional Columns
Unscrew the cover of the additional bases and take it out with a flat screwdriver.
1.
Insert the bases into each other as projected and secure their position with the
2.
small side wedges and screws.
Place the cover on the flush mounting box / predrilled holes with dowels and pull
3.
the cables if any through the bottom holes.
Pull the bus using the cable bushing available in the flush mounting box.
4.
Main Unit
Power Supply Connection
2N® IP Verso can be powered either from an external 12 V / 2 A DC source or directly
from the LAN equipped with PoE 802.3af supporting network elements. Owing to
different power outputs, the power supply selection affects the maximum count and
applicability of the modules connected of the main unit.
External power supply
Use a 12 V ±15 % SELV supply dimensioned to the minimum current consumption of 2
A (Part No. 91341481E) to make your system work reliably. This power supply provides
®
2N IP Verso with 24 W for feeding of the main unit and connected modules.
PoE Power Supply
®
2N IP Verso is compatible with the PoE 802.3af (Class 0–12,95 W) technology and
can be fed directly from the LAN via the compatible network elements. If your LAN
does not support this technology, insert a PoE injector, Part No. 91378100, between 2N
®
IP Verso and the nearest network element. This power supply provides
with 12 W for feeding of the main unit and connected modules.
Combined Power Supply
®
2N IP Verso can be fed from an external power supply and PoE at the same time. In
this configuration, the maximum power for the connected modules is available.
