F-1-1. System Settings - FOR-A FA-1010 Update Manual

F-1-1. System Settings

No. Menu item
①
Unity Mode
②
Front Buzzer
③
GPI Buzzer
④
Display Mode
⑤
Display BRIGHT
⑥
GPI1 No.1-10
⑦
GPI2 No.11-20
⑧
GPI3 No.21-30
⑨
IP:192.168.0.100
⑩
Subnet
255.255.255.0
⑪
Gateway 0.0.0.0
⑫
(*2)
FAN
⑬
Soft Ver:1.00
⑭
FPGA1 Ver:1.00
⑮
FPGA2 Ver:1.00
(*1) See section 8-2. "GPI OUT LED Indicator Brightness Settings." in the FA-10DCCRU Operation Manual.
(*2) When the fan has stopped, turn off the unit power, notify your FOR-A reseller or supplier and change the
fan.
Setting buttons
－, ＋ buttons － Unlinked:
UNITY is applied only to the relevant FS channel.
＋ Linked:
UNITY is applied to all linked FS channels.
－, ＋ buttons － Disable: Disables the front buzzer.
＋ Enable: Enables the front buzzer.
－, ＋ buttons － Disable: Disables the buzzer for GPI settings.
＋ Enable: Disables the buzzer for GPI settings.
－, ＋ buttons － Full: Displays settings in detailed format.
＋ Simple: Displays settings in short format.
－, ＋ buttons
Sets front panel brightness.
Options are 1.7%, 3.3%, 5%, 6.7%, 8.3%, 11.7%, 15%,
18%, 23%, 30%(default), 37%, 47%, 60%, 80%
and100%
(*1)
Rotary encoder Sets brightness for GPI OUT LED indicators (No1 – 10)
from 0 to 255. (Default: 50)
(*1)
Rotary encoder Sets brightness for GPI OUT LED indicators (No11 – 20)
from 0 to 255. (Default: 50)
(*1)
Rotary encoder Sets brightness for GPI OUT LED indicators (No21 – 30)
from 0 to 255. (Default: 50)
(Display only) Displays the FA-10DCCRU IP address.
(Display only) Displays the FA-10DCCRU subnet mask.
(Display only) Displays the FA-10DCCRU default gateway.
(Display only) Displays the FA-10DCCRU fan status.
Normal: The fan is functioning normally.
Stopped: The fan has stopped.
(Display only) Displays the software version.
(Display only) Displays the FPGA1 version.
(Display only) Displays the FPGA2 version.
Description
