4. FA-1010 Update

4-1. Software Update (PM9222) (Required Time: 1 sec.)

1. Connect the FA-1010 and PC using a LAN cable.
2. Start the FA1010 Updater.exe file (Fig. 12).
3. Enter the IP address (default IP address: 192.168.0.10)(Fig. 13 ①).
4. Check [FA-1010 Soft] under [Target] (Fig. 13 ②).
5. Select the latest version software under [Update File] (Fig. 13 ③).
6. Click [Update] to start updating. (Fig. 13 ④).
The selected file needs to be in .ais format with a file name that begins with "FA1010_".
If an error occurs, verify that the data is FA-1010 software data.
7. A message appears when the update is complete.
Fig. 13 FA-1010 Program Updater dialog
Fig. 12. FA1010Updater.exe
(for Software update settings)
① Enter the IP address
② Check FA-1010 Soft
③ Select the latest software data
④ Click Update
