3-2-5. FA-10GPI

1) Nest connectors on the option card into the slot, align screw holes, then lightly secure the

card with the supplied double-SEMS screws.

2) Secure the option card to the rear panel with the binding screws removed in Common

Installation/Removal Procedure.

3) Tighten double-SEMS screws.

Fig. 11 FA-10GPI Installation

Insert and secure card into

place first, then tighten

binding screws.
