Start A Cut From The Edge Of The Workpiece - Hypertherm Powermax45 SYNC Operator's Manual

4
Cut and Mark with the Hand Torch

Start a cut from the edge of the workpiece

Slag produced during piercing can cause damage to the tip of the cartridge. Start the cut from the
edge of the workpiece, when possible, to decrease this damage and to optimize cartridge life.
1. With the work clamp attached to the workpiece, hold the torch tip perpendicular (90°) to the
edge of the workpiece.
2. Pull the torch's trigger to start the arc. Stay at the edge until the arc has cut completely through
the workpiece.
68 811470 Operator Manual Powermax45 SYNC
