Step 5 – Set the power switch to ON (I)
Set the power switch to ON (I). The
switch is on the front panel of the
plasma power supply.
If the torch-lock switch is set

to the green "ready to
fire" ( ) position when you
set the power switch to ON,
the hand torch puts out a
puff of air. Refer to
puffs of air
If the torch-lock switch is set

to the yellow lock (X)
position when you set the
power switch to ON, the
Torch Cap LED on the front
panel comes on.
Powermax45 SYNC Operator Manual
Warning
on page 52.
811470
Operate the Plasma System
400 V, 480 V
200 V – 240 V
3
51
