Install and Set Up the Plasma Power Supply

Make sure that you have all the system components

2
1 Documentation
• Product Safety Information and
Instructions (811500MU)
• Radio Equipment Directive (810600MU)
• Fault code labels (811490MU)
• Powermax45 SYNC Getting Started
Guide (811550MU)
2 SmartSYNC cartridge
®
* CE/CCC and 480 V CSA models: power cord with no power plug
CSA 200 V – 240 V models: power cord with 50 A, 250 V plug (NEMA 6-50P)
18
1
3
4
3 15° or 75° hand torch with lead or
4 Work clamp with work lead
5 Remote-start pendant (optional – mechanized
6 Power cord*
7 Region-specific gas inlet fitting (may not be
8 Plasma power supply
8
5
machine torch with lead
configurations only)
preinstalled)
811470 Operator Manual
7
6
