nAttaching the base
1� Place the monitor face down on a non-abrasive surface
(Figure 1)�
2� Please rotate the stand 90 degrees as shown in Figure 1�
3� Attach the base to the stand, then tighten the screw at the
base's bottom (Figure 2)�

TIP: Reverse this procedure if you need to re-pack the monitor.
nHeight and angle adjustment
Hold the monitor on each side and adjust the screen position as desired.
For screen rotation (pivot), hold the monitor on each side, lift to its maximum height and turn it from landscape to portrait.
You can adjust the OSD (On-Screen Display) menu rotation to match the screen rotation. Refer to the [OSD ROTATION]
instructions (see page 29).
Rotation, Raise and Lower
nRemoving the stand

TIP: Handle with care when removing the monitor stand.
1

Installation

2
90°
Tilt and Swivel
3
English−12
Figure 1
NOTE:
4
Screw
Figure 2
