  • Page 1 LCD Monitor LCD Farbmonitor Moniteur LCD Monitor LCD Monitor LCD !"==== LL-T15G3 OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EPLOI MANUALE D’USO MANUAL DE FUNCIONAMIENTO !"...

  • Page 2: Notice For Users In Europe

    Notice for Users in Europe This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE.

  • Page 3: Notice For Users In The Uk

    "WARNING :THIS APPARATUS MUST BE EARTHED" Notice for Users in Australia Service Inquiries Please contact your dealer for service if required or contact Sharp Corporation of Australia on 1 300 13 50 22 for referral to your nearest Sharp authorized Service Center.

  • Page 4: Notice For Users In The Usa

    Sharp Plaza, Mahwah, New Jersey 07430 TEL :1-800-BE-SHARP * As an ENERGY STAR Partner, SHARP has determined that this product meets the ENERGY STAR guidelines for energy efficiency. This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury.
  • Page 5 Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame LL-T15G3-B LL-T15G3-H retardant substances. Most flame retardants contain...

  • Page 6: Table Of Contents

    Table of Contents Tips and safety precautions ............. 8 Product description .

  • Page 7: Tips And Safety Precautions

    - Sharp Corporation holds authorship rights to the during use, except where indemnity liability is Utility Disk program. Do not reproduce it without recognized under law.

  • Page 8: Product Description

    Product description 1. MENU button ......This button is used to pop-up, select and close the OSD (On Screen Display) Menu. / MODE button ..... When the OSD Menu is displayed: This button is used to select menu options. When the OSD Menu is not displayed: This button is used to set COLOR MODE.
  • Page 9 Product description Standing up and adjusting the monitor Angle adjustment Press down on the stand and adjust it to a suitable viewing angle. CAUTION! approx.5° approx.25° - Pressure from hands on the LCD panel could cause damage. - Be careful not to allow your fingers to be pinched.

  • Page 10: Connecting The Monitor And Turning The Monitor On And Off

    Connecting the monitor and turning the monitor on and off CAUTION! Connecting the monitor to a power source - When connecting, ensure that both the monitor and computer are switched off. - Be careful not to overly bend the cable or add Power terminal extension cords as this could lead to a malfunction.

  • Page 11: Installing Set-Up Information And The Icc Profile (For Windows)

    Connecting the monitor and turning the monitor on and off For Windows98 Installing set-up information and the Installing monitor set-up information into Win- ICC profile (for Windows) dows98, and setting the monitor's ICC profile as a Depending on the computer or OS, it may be predetermined value.
  • Page 12 Connecting the monitor and turning the monitor on and off For Windows2000 If the "Add New Hardware Wizard" has not ap- peared: Installing monitor set-up information into Win- dows2000, and setting the monitor's ICC profile as 1. Place the Utility Disk in the computer's A drive. a predetermined value.

  • Page 13: Information About The Colorsync Profile (For Macos)

    Connecting the monitor and turning the monitor on and off Installing the ICC profile Information about the ColorSync Installing the monitor’s ICC profile. (If the set-up profile (for MacOS) information has already been installed, so too has the profile, and there is no need to install it.) This explanation assumes that the floppy disk drive About the ColorSync profile is "A drive".

  • Page 14: Adjusting The Screen Display

    Adjusting the screen display Adjustment lock function Adjustment the backlight (right column) Brightness of backlight can be adjusted. By disabling the control buttons (i.e. setting the lock) any attempted changes to adjusted values will COLOR MODE setting (p. 16) be voided. Color tone can be set.

  • Page 15: Setting Color Mode

    Adjusting the screen display Setting color mode Automatic screen adjustment Options in the ADJUSTMENT Menu can be Color tone can be set as below. adjusted automatically (CLOCK, PHASE, H-POS, V-POS). Displays image with the color tone results from Note: original scheme of liquid crystal panel. - When setting up this monitor for the first time or after having changed an aspect of the current sRGB...

  • Page 16: Manual Screen Adjustment

    Adjusting the screen display Adjusting the screen automatically Manual screen adjustment 1. Press the MENU button. Adjustments can be made using On Screen The ADJUSTMENT Menu will be displayed. Display (OSD) Menu provided. ADJUSTMENT 1.Display an image that makes the entire screen MANUAL AUTO very bright.
  • Page 17 Adjusting the screen display ADJUSTMENT Menu GAIN CONTROL Menu ADJUSTMENT GAIN CONTROL MANUAL AUTO MANUAL AUTO CLOCK BLACK LEVEL PHASE CONTRAST H-POS V-POS 1024x768 1024x768 V : 6 0Hz H : 4 8.4kHz V : 6 0Hz H : 4 8.4kHz MANUAL: Individual menu options are manually MANUAL: Individual menu options are manually adjusted.
  • Page 18 Adjusting the screen display WHITE BALANCE Menu MODE SELECT Menu WHITE BALANCE MODE SELECT OSD H-POSITION COOL WARM USER OSD V-POSITION SCALING HIGH R-CONTRAST COLORS 260K G-CONTRAST LANGUAGE B-CONTRAST 1024x768 1024x768 V : 6 0Hz H : 4 8.4kHz V : 6 0Hz H : 4 8.4kHz Notes: Notes: - On settings other than [STD] not all graduations...

  • Page 19: Monitor Care And Repair

    Use a soft dry cloth to lightly wipe away dirt and inquire at the shop where you purchased the dust from the surface of the LCD panel. (A soft monitor or your nearest Sharp authorized cloth such as gauze or that used for lens cleaning Service Center. (Never attempt this is suitable.)

  • Page 20: Specifications

    Specifications Product specifications Dimensions (Units: mm) LCD display 38 cm measured diagonally TFT LCD module Resolution (max.) XGA 1024 x 768 pixels Displayable colors (max.) Approx.16.19 million colors (6bit + FRC) Brightness (max.) 260cd/m Dot pitch 0.297(H) x 0.297(V) mm Contrast ratio 350:1 Angle of visibility...
  • Page 21 Specifications Signal timings Power management The monitor is based on VESA DPMS (Display Display mode Hsync Vsync Power Management Signaling). frequency To activate the monitor's Power Management 640x480 31.5kHz 60Hz 25.175MHz VESA function, both the video card and the computer 37.9kHz 72Hz 31.5MHz...

  • Page 22: Instructions For Attaching A Vesa Compliant Arm

    Instructions for attaching a VESA compliant arm An arm or stand based on the VESA standard 6. Attach the arm to the monitor with four screws. (commercially available) can be attached to the monitor. Procurement of the arm or stand is at the custom- er's discretion.
  • Page 23 Instructions for attaching a VESA compliant arm The stand may be removed. 1.Turn off the monitor, and remove the analog signal cable and the power cord from the monitor. 2. Being careful not to damage the monitor, spread out a soft cloth and lay the monitor on it display- side down.
  • Page 24 SHARP CORPORATION © 2002 SHARP CORPORATION Printed in Taiwan P/N: 0NIT15G3-E001 1925-1300-4320...
