Sharp MultiSync EA272Q User Manual page 26

Menu Items
SCREEN
n
SCREEN Menu
VIDEO LEVEL
HDMI input only
NORMAL
EXPAND
OVER SCAN
HDMI input only
ON
OFF
EXPANSION
FULL
ASPECT
RESPONSE IMPROVE
UNIFORMITY
SHARPNESS
COLOR
n
COLOR Menu
Color Control System
1, 2, 3, 4, 5
NATIVE
L/B (LOW BLUE LIGHT)
DICOM SIM.
PROGRAMMABLE
Setting for use with a computer. Displays all input signals of 0-255 steps.
Setting for use with audio visual equipment. Expands input signals of 16-235 steps to 0-255 steps.
Some video formats may require different scanning modes in order to best display the image.
Image size is larger than what can be displayed. The image edge will appear cropped. Approximately
95 % of the image will be shown on the screen.
Image size stays within the display area. The whole image is displayed on the screen.
Sets the zoom method.
The image is expanded to full screen regardless of the resolution.
The image is expanded without changing the aspect ratio.
Turns the [RESPONSE IMPROVE] function [ON] or [OFF]. This function may reduce blurring that occurs
in some moving images.
This function electronically compensates for the slight variations in the white uniformity level as well as
for deviations in color that may occur throughout the display area of the screen. These variations are
characteristic of LCD panel technology. This function improves the color and evens out the luminance
uniformity of the display.

NOTE: Using the UNIFORMITY feature does reduce the overall peak luminance of the display. If greater
luminance is desired over the uniform performance of the display, then UNIFORMITY should be
turned off. "ON" produces a better effect, but may also reduce the CONTRAST RATIO.
Adjusts the crispness of the image.
Color presets are available for adjusting color settings.
Increases or decreases the [RED], [GREEN] or [BLUE] color depending upon which is selected.
The change in color will appear on screen and the direction (increase or decrease) will be shown by the
bars. sRGB (color preset mode [4]) dramatically improves the color fidelity in the desktop environment by
a single standard RGB color space. With this color-supported environment, the operator could easily and
confidently communicate color without further color management overhead in most common situations.
The LCD panel's original colors that cannot be adjusted.
Reduces blue light emitted from monitor. This item cannot be adjusted.

TIP: You can directly change to [L/B] (LOW BLUE LIGHT) by touching the INPUT/SELECT key for
3 seconds or more. Low Blue Light function substantially reduces blue light and helps to alleviate
eye-strain. For changing to other settings from [L/B], touch the MENU/EXIT key to show OSD menu
and enter Color Control System.

W hen [L/B] is selected in Color Control System, [CONTRAST] and [DV MODE] are disabled.
The white point color temperature and the gamma curve are set to a DICOM simulation. This item cannot
be adjusted.
NOTE:

Do not use for diagnostic purposes.
The gamma curve is adjustable through application software.
* This function is not available with this monitor.
English−26
