To attach a VESA-compliant mounting bracket, use M4 screws that are 6 mm to 10 mm longer than the thickness of the
mounting bracket.
•
Be sure to use a wall-mount bracket designed or designated for mounting the monitor.
•
This monitor and bracket must be installed on a wall which can endure at least 4 times or more the weight of the monitor.
Install by the most suitable method for the material and the structure.
•
Do not use an impact driver.
•
Do not use any screw holes other than those for mounting brackets, located on the rear of the monitor, for installation.
•
When installing, check the tilt angle in the Product Specifications
•
After mounting, please carefully ensure the monitor is secure, and not able to come loose from the wall or mount.
nInstalling a security cable and prevent tipping
As a security measure, you can secure the monitor to a fixed object with an
optional security cable.
Please follow the security cable supplier's recommended instructions to install.
A security cable (purchased separately) is designed as a deterrent, it is not
guaranteed to prevent the device from being mishandled or stolen.
When using the monitor, fasten the monitor to a wall using a cord that can
support the weight of the monitor in order to prevent the monitor from falling.
Installing must be done by a qualified technician, and please contact your
supplier for more information.
6 - 10 mm
Screws (M4)
Mounting bracket
Monitor mounting
(page
9
≦ 5°
English−44
42).
> 5°
