Programming Guide | VLT® Aqua Drive FC 202
Set the rotor resistance value R
Run an AMA on a cold motor. The drive measures the value from the motor. All compensations are reset to 100%.
l
Enter the R
value manually. Obtain the value from the motor supplier.
l
r
Use the R
default setting. The drive establishes the setting based on the motor nameplate data.
l
r
1-33 Stator Leakage Reactance (X1)
Default value:
Size related
Setup:
All setups
Data type:
Uint32
This parameter is only relevant for asynchronous motors.
Set the stator leakage reactance of the motor using 1 of these methods:
Run an AMA on a cold motor. The drive measures the value from the motor.
l
Enter the X
value manually. Obtain the value from the motor supplier.
l
1
Use the X
default setting. The drive establishes the setting based on the motor nameplate data.
l
1
The parameter value is updated after each torque calibration if option [3] 1st start with store or option [4] Every start with store is
selected in parameter 1-47 Torque Calibration.
1-34 Rotor Leakage Reactance (X2)
Default value:
Size related
Setup:
All setups
Data type:
Uint32
This parameter is only relevant for induction motors.
Set the rotor leakage reactance of the motor using 1 of these methods:
Run an AMA on a cold motor. The drive measures the value from the motor.
l
Enter the X
value manually. Obtain the value from the motor supplier.
l
2
Use the X
default setting. The drive establishes the setting based on the motor nameplate data.
l
2
The parameter value is updated after each torque calibration if option [3] 1st start with store or option [4] Every start with store is
selected in parameter 1-47 Torque Calibration.
1-35 Main Reactance (Xh)
Default value:
Size related
Setup:
All setups
© 2024.06
to improve shaft performance using 1 of these methods:
r
Parameter type:
Conversion index:
Change during operation:
  NOTICE
  NOTICE
Parameter type:
Conversion index:
Change during operation:
  NOTICE
  NOTICE
Parameter type:
Conversion index:
Parameter Descriptions
Range, 0.0400 - 400.0000 Ohm
-4
False
Range, 0.0400 - 400.0000 Ohm
-4
False
Range, 1.0000 - 10000.0000
[Ohm]
-4
AU361182657213en-002101 / 130R0338 |
91
