Programming Guide | VLT® Aqua Drive FC 202
Select the start function during start delay. This parameter is linked to parameter 1-71 Start Delay.
Option
[0]
[2]*
1-73 Flying Start
Default value: –
Setup:
All setups
Data type: Uint8
This function is not recommended for hoisting applications. For power levels above 55 kW, flux mode must be used to achieve the
best performance.
To obtain the best flying start performance, the advanced motor data, parameter 1-30 Stator Resistance (Rs) to parameter 1-35
Main Reactance (Xh), must be correct.
This function makes it possible to catch a freely spinning motor, for example coasted because of mains dropout. When parameter 1-73
Flying Start is enabled, parameter 1-71 Start Delay has no function. Search direction for flying start is linked to the setting in parameter
4-10 Motor Speed Direction. [0] Clockwise: Flying start searches in clockwise direction. If not successful, a DC brake is carried out. [2] Both
Directions: The flying start first searches in the direction determined by the last reference (direction). If the speed is not found, flying start
searches in the other direction. If not successful, a DC brake activates in the time set in parameter 2-02 DC Braking Time. Start then takes
place from 0 Hz.
Option Name
[0] Disabled
[1] Enabled
[2] Enabled always
[3] Enabled ref. dir.
[4] Enab. always ref. dir.
[11] v2 Enabled
[12] v2 Enabled Always
[13] v2 Enabled Ref. Dir.
[14] v2 Enab. Alw. Ref. Dir.
© 2024.06
Name
DC hold/motor preheat
Coast
Description
Energize the motor with a DC hold current
(parameter 2-00 DC Hold Current) during the start
delay time.
Motor coasted during the start delay time (inverter
off ).
Parameter type:
Conversion index:
Change during operation:
NOTICE
NOTICE
Description
No function.
Enable after coast.
Enable at every start.
Enable after coast, search in reference direction only.
Enable at every start, search in reference direction only.
Enable flying start version 2, after coast.
Enable flying start version 2, at every start.
Enable flying start version 2, after coast, search in reference
direction only.
Enable flying start version 2, ok at every start, search in reference
direction only.
Parameter Descriptions
Option
–
False
