Danfoss VLT Aqua Drive FC 202 Programming Manual page 90

Programming Guide | VLT® Aqua Drive FC 202
Par. 1-30
I
q
R
s
U
d
d-axis equivalent circuit
Par. 1-30
I
q
R
s
U
q
q-axis equivalent circuit
Figure 30: Motor Equivalent Circuit Diagram for a PM Non-salient Motor
1-30 Stator Resistance (Rs)
Default value: Size related
Setup: All setups
Data type: Uint32
Set the line-to-common stator resistance value. Enter the value from a motor datasheet or perform an AMA on a cold motor.
This parameter cannot be adjusted while the motor is running.
The parameter value is updated after each torque calibration if option [3] 1st start with store or option [4] Every start with store is
selected in parameter 1-47 Torque Calibration.
1-31 Rotor Resistance (Rr)
Default value: Size related
Setup:
All setups
Data type: Uint32
Parameter 1-31 Rotor Resistance (Rr) has no effect when parameter 1-10 Motor Construction is set to [1] PM, non-salient SPM, [2]
PM, salient IPM, [5] SynRM, and [6] PMaSynRM.
90 | © 2024.06
ω L I
Par. 1-37
s q q
L
d
+
Par. 1-37 ω L I
s d d
L =L
q d
+
-
-
+
Par. 1-40
ω λ
s PM
-
Parameter type:
Conversion index:
Change during operation:
NOTICE
NOTICE
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter Descriptions
Range, 0.0140 - 140.0000 Ohm
-4
False
Range, 0.0100 - 100.0000 Ohm
-4
False
AU361182657213en-002101 / 130R0338
