1. Product summary

1.1. Features

The SI (Serial Interface) Unit is an EtherCAT
manifolds.
EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
®
Germany.
The SI Unit controls a 64 station compatible manifold and has the following properties:
 IP67 protection
 Two M8 connectors (4 pin socket, A-coded) for EtherCAT
 Two M8 connectors (4 pin plug/socket, A-coded) for power supply
 Up to 64 stations / 128 solenoid valves connectable
 CoE supported for parameter setting and diagnostics etc.
 FoE supported
 SM Synchronous and DC Synchronous supported
 Integrated diagnostic and protection function
 Galvanically isolated power supplies
Corresponding solenoid valve manifold
 JSY series 64 station compatible manifold series
compatible device for control of SMC pneumatic valve
®
connection
®
-10-
No.DOC1041432
