5.2. Output counter limit value (Index 0x80x1)

Subindex Output Set value
[hex] No.
0x01 1st
0x02 2nd
0x03 3rd
0x04 4th
0x05 5th
0x06 6th
4294967295
0x07 7th
0x08 8th

5.3. Output count reset (Index 0x80x2)

Write value[hex]
0x00
...
0xFF
Write value
[hex]
0x56
0xBC
5.4. Output counter (Index 0x90x0)
Subindex[hex] Output No.
0x01 1st
0x02 2nd
0x03 3rd
0x04 4th
0x05 5th
0x06 6th
0x07 7th
0x08 8th
Table 5-4. Output counter limit value
Default
[Dec]
0
1
2 4294967295
...
Table 5-5. Output count reset
Reset the valve output counter value. Refer to
Set by 1 byte value with 1 bit per output.
0[bin]: No output count reset request
1[bin]: Output count reset request
Table 5-6. Example of Output count reset
Write value [bin] and the Output count reset (0: No reset, 1: Reset)
8th 7th 6th
0 1 0
1 0 1
Table 5-7. Output counter
Read value[dec]
0
1
2
...
4294967295
Set valve output counter limit value.
One Index contains 8 Subindex and can be set for each
output.
If the number of times the valve output is turned on exceeds
the set value, a diagnosis occurs.
If set to the default value 4294967295, the output count over
diagnosis is disabled.
Output count reset is resumed by the CoE, refer to
5.3.
Description
5th 4th
1 0
1 1
Read valve output count number.
One Index contains 8 Subindex, and the count value can
be read for each output.
-20-
Description
Section 5.4.
3rd 2nd 1st
1 1 0
1 0 0
Description
No.DOC1041432
