5. CoE

This section describes the Index related to product specifications.
Index *1 Subindex
0x70x0 -
0x80x0 -
0x80x1 0x01...0x08 Output counter limit value OUTa_b
0x80x2 -
0x90x0 0x01...0x08 Output counter OUTa_b
0xA0x0 -
0xF000 0x01...0x02 Modular Device Profile
0xF030 0x01...0x10 Configured Module Ident List
0xF050 0x01...0x10 Detected Module Ident List
0xF100 0x01...0x05 Unit diagnosis
0xFB00 -
NOTE
 *1) The Index with "x" corresponds to the output No. for which the "8 valve" module is set in Slots.
The x contains 0 to F, e.g. 2 corresponds to OUT16_23.
( �� [ ������ ] = �� [ ℎ���� ] × 8,
 *2) "RO" means Read only, "WO" means Write only, and "RW" means both Read and Write are
allowed.
Those with a trailing P are the Index assigned to the process data.

5.1. Output operation at network fault (Index 0x80x0)

Set value[hex] Default
0x0000
... 0x0000
0xFFFF
Set value
[hex]
0x1245
0x689A
Table 5-1. Overview of CoE
Name
Valve Output OUTa_b
Output operation at network fault OUTa_b
Output count reset OUTa_b
Output short circuit diagnosis OUTa_b
Output count batch reset
�� [ ������ ] = �� [ ℎ���� ] × 8 + 7 )
Table 5-2. Output operation at network fault
Set valve output operation when a communication error occurs.
Set by 2 byte value with 2 bit per output.
 00 [bin]: Force to OFF (Forces the output to turn off.)
 01 [bin]: Force to ON (Forces the output to turn on.)
 10 [bin]: Hold last state
(The output state immediately before the communication error is maintained.)
 11 [bin]: Unused (Same as setting to force the output turn OFF.)
Table 5-3. Example of the Output operation at network fault
Set value [bin] and the Output operation at network fault
(00: Force to OFF, 01: Force to ON, 10: Hold last state)
8th 7th 6th
00 01 00
01 10 10
Flags *2
RO P
RW
RW
WO
RO
RO P
RO
RW
RO
RO P
WO
Description
5th 4th 3rd
10 01 00
00 10 01
-19-
Description
Refer to Section 4.2.1.
Refer to Section 5.1.
Refer to Section 5.2.
Refer to Section 5.3.
Refer to Section 5.4.
Refer to Section 4.1.1.
Index distance: 0x0010
Maximum number of
modules: 0x0010
Refer to Section 5.5.
Refer to Section 4.1.2.
Refer to Section 5.6.
2nd 1st
01 01
10 10
No.DOC1041432
