SMC Networks EX260-MEN1 Operation Manual

Fieldbus system ethernet/ip compatible si unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Doc. DOC1073641
PRODUCT NAME
Fieldbus system
EtherNet/IP
compatible SI Unit
TM
MODEL / Series / Product Number
EX260-MEN1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX260-MEN1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks EX260-MEN1

Summary of Contents for SMC Networks EX260-MEN1

  • Page 1 Doc. DOC1073641 PRODUCT NAME Fieldbus system EtherNet/IP compatible SI Unit MODEL / Series / Product Number EX260-MEN1...

  • Page 2: Table Of Contents

    Contents Safety instructions 1. Product summary 1.1. Features 1.2. Summary of Product elements 2. Wiring 2.1. Installation 2.2. Wiring 2.3. FE terminal 3. Configuration 3.1. EDS file and Icon file 3.2. Switch setting 3.3. Configuration with Studio 5000 Logix Designer 3.4.
  • Page 3 7. LED display 8. Specification 8.1. Dimensions 8.2. Specifications 9. Accessories 9.1. Accessories for communication connector 9.2. Accessories for power connector 10. Troubleshooting 10.1. Troubleshooting chart 10.2. Troubleshooting tables No. DOC1073641...

  • Page 4: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of "Caution", "Warning" or "Danger". They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 5 Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
  • Page 6 Operator ♦This operation manual is intended for those who have knowledge of machinery using pneumatic equipment, and have sufficient knowledge of assembly, operation and maintenance of such equipment. Only those persons are allowed to perform assembly, operation and maintenance. ♦Read and understand this operation manual carefully before assembling, operating or providing maintenance to the product.
  • Page 7 Caution ■When handling or assembling or replacing the unit, pay attention to the following: •Do not touch the sharp edges when overseeing the unit. •The unit joints are tightly bound with gaskets, so do not hit your hands when replacing the unit. •Do not put your fingers between them when joining the units.
  • Page 8 •Product handling ∗Installation •Do not drop, hit or apply excessive shock to the fieldbus system. Otherwise, damage to the product can result, causing malfunction. •Tighten to the specified tightening torque. If the tightening torque is exceeded the mounting screws may be broken. IP67 protection cannot be guaranteed if the screws are not tightened to the specified torque.
  • Page 9 •Mount the product in a place that is not exposed to excessive vibration or impact. Otherwise, failure or malfunction can result. •Do not use the product in an environment that is exposed to temperature cycle. Heat cycles other than ordinary changes in temperature can adversely affect the inside of the product. •Do not expose the product to direct sunlight.
  • Page 10 Fieldbus System/ Industrial IoT Cybersecurity In recent years, factories have introduced industrial IoT, building up complex networks of production machines. These systems maybe subject to a new threat, cyberattack. To protect the industrial IoT from cyberattacks, it is important to take multiple measures (multi-layer protection) for IoT devices, networks and clouds.

  • Page 11: Product Summary

    1. Product summary 1.1 Features SI (serial interface) unit is an EtherNet/IP™ device for pneumatic solenoid valves manufactured by SMC. The SI unit can control a 64 (2 solenoid valves per station) stations valve manifold and has the following characteristics. ・Protection rating of enclosure IP67 ・Two M12 connectors (4-pin socket, D-code) for EtherNet/IP™...

  • Page 12: Wiring

    2. Wiring Select the appropriate cables to mate with the connectors mounted on the SI Unit, refer to Section 2.1. Installation 2.1.1. Valve manifold connection Connect the valve manifold to the SI unit and secure with two hexagon socket head screws (M3 x 30).

  • Page 13: Wiring

    2.1.2. Valve manifold installation SI unit does not have mounting holes for installation. For installation, refer to the instruction manual or catalog of the valve manifold to be used. Fig.2.2 Top view of valve manifold 2.2. Wiring Connect the power cable, EtherNet/IP™ cable, and function grounding cable. (1) M12 4-pin socket D cord, EtherNet/IP™...
  • Page 14 2.2.1. Communication connector BUS IN/Port 1 BUS OUT/Port2 Port type: MDI Port type: MDI-X Pin No. Designation Content Designation Content Transmit Data + Receive Data + Receive Data + Transmit Data + Transmit Data - Receive Data - Receive Data - Transmit Data - M12 4 pin socket D-coded connector...
  • Page 15 The following Fig. 2.6 shows wiring examples of the use of two cable types. Patch cable Pin No. Pin No. MDI-X TD+ Transmit data+ RD+ Receive data+ RD+ Receive data+ TD+ Transmit data+ TD+ Transmit data- RD- Receive data- RD- Receive data- TD+ Transmit data- Crossover cable Pin No.

  • Page 16: Fe Terminal

    2.2.2 Power connector Pin No. Designation Content 24 V (PWR) 24 VDC for Control 24 V (PWR(V)) 24 VDC for output 0 V (PWR) 0 VDC for Control 0 V (PWR(V)) 0 VDC for output M12 4 pin socket A-coded connector (PWR) Fig.2.7 Pin allocation of power connector The power supply for Control (PWR) and the power supply for output (PWR(V)) are isolated.

  • Page 17: Configuration

    3. Configuration 3.1. EDS file and Icon file The compatible EDS file is required to configure the SI Unit within an EtherNet/IP network. Download the latest EDS files from our website. URL: https://www.smcworld.com EDS files and icon files are as follows. EDS file : ex260_men_128_v***.eds Icon file...
  • Page 18 *1 : Remote control (Set rotary switch for IP address X to 000) The remote control mode is compatible with the IP address setting software EX9-ZSW-IPC1. Using EX9-ZSW-IPC1, you can set IP addresses for up to 200 x devices while checking the MAC addresses of connected devices.

  • Page 19: Configuration With Studio 5000 Logix Designer

    3.3. Configuration with Studio 5000 Logix Designer This section shows how to connect an SI Unit to a Rockwell Automation EtherNet/IP module (PLC). Examples are given here using Studio 5000 Logix Designer. For detailed operating instructions, refer to the Studio 5000 Logix Designer operation manual. Note: The screens shown below are Rockwell Automation software Studio 5000 Logix Designer.
  • Page 20 - The Select Module Type screen is displayed. Select ETHERNET-MODULE Generic Ethernet Module and click the Create button. Fig.3.3 Configuration procedure without EDS file (Step2) -20- No. DOC1073641...
  • Page 21 - The New Module screen is displayed. Make the following setting changes. (1) Name : Enter any unit name. (2) Comm : Select the data format for Connection Parameters. (3) IP Address : Enter the IP address set for the SI Unit. (4) Assembly Instance : Enter as shown below.
  • Page 22 3.3.2. To set up with EDS file - Install the EDS file beforehand using the Rockwell Automation software Rockwell EDS Wizard Tool or similar. For installation instructions, refer to the manual of the Rockwell EDS Wizard Tool or other software. When the EDS file is installed, the SI Unit part number will be added to the Select Module screen.
  • Page 23 - The New Module screen is displayed. Make the following setting changes. (1) Name : Enter an unit name. (2) IP Address : Enter the IP address set for the SI Unit. Fig.3.6 Configuration procedure with EDS file (Step 2) -23- No.

  • Page 24: Ethernet/Ip Tm Functionprocess Data

    3.4. EtherNet/IP function 3.4.1. DLR (Device Level Ring) function The SI Unit can be used as an EtherNet/IP compliant Ring Node supporting the DLR function. To enable the DLR function, all Ring Nodes must support the DLR function. All settings for the DLR function are made by the Ring Supervisor, so there are no settings that need to be made on the SI Unit.

  • Page 25: Process Data

    4. Process data 4.1. Input process data Byte Content Description 0：No short circuits Short circuit diagnostic 1：At least one output has short circuit 0：No Manifold block configuration error Manifold block configuration 1：ON command is received for an output(s) on diagnostic unconnected manifold block 0：No output count over Output counter diagnostic...

  • Page 26: Output Process Data

    4.3. Process data mapping Fig.4 Output process data mapping -26- No. DOC1073641...

  • Page 27: Ethernet/Ip Tm Object Implementation

    5. EtherNet/IP Object implementation 5.1. Identity Object (Class ID：01h) 5.1.1. Instance Attribute Access rule Content Value Vender ID Device Type Product Code 109h Revision Refer to product label Status Serial Number Refer to product label Product Name EX260-MEN 5.1.2. Instance common service Service code Service name Value...
  • Page 28 ○Exclusive Owner Consumed Data (96h) Octet OUT7 OUT6 OUT5 OUT4 OUT3 OUT2 OUT1 OUT0 OUT15 OUT14 OUT13 OUT12 OUT11 OUT10 OUT9 OUT8 OUT23 OUT22 OUT21 OUT20 OUT19 OUT18 OUT17 OUT16 OUT31 OUT30 OUT29 OUT28 OUT27 OUT26 OUT25 OUT24 OUT39 OUT38 OUT37 OUT36 OUT35...

  • Page 29: Discrete Output Point Object (Class Id: 09H)

    5.3. Discrete Output Point (Class ID：09h) 5.3.1. Instance Attribute Access rule Content Value 0：Output OFF Get/Set Output status 1：Output ON Instance Content 01h - 80h Number of Output channel (OUT0 - OUT127) 5.3.2. Instance common service Service Code Service Name Value 0x0E Get Attribute Single...

  • Page 30: Smc Si (Vendor Specific) Object 2 (Class Id: 65H)

    5.5. Vendor Specific Object 2 (Class ID: 65) 5.5.1. Instance attribute Access rule Content Description 0：No error 1：Error is detected Output diagnostic Bit 0：Short circuit Bit 1：Output count limit Bits 2-7：Reserved (Fixed to 0) 0 to 4,294,967,295 ※1 Get/Set Output counter limit value (UDINT: 32-bit unsigned int) 0 to 4,294,967,295 ※...

  • Page 31: Web Server

    6. Web server The SI Unit has a web server function. From a PC web browser, you can perform checking SI Unit's diagnostics, setting parameters and forcing output etc.. Connect the SI Unit and the PC to the same Ethernet network and launch the PC's web browser. Enter the IP address of the SI Unit in the address bar of the web browser to connect to the web server.

  • Page 32: System Information Tab

    6.1. System information tab ① ② ③ Fig.6.1 System information tab Table 6.2 Content of System information tab Item Description System Information Displays system information of the SI unit. Network Displays network configurations. Displays Device Information of the SI unit. Device Information (Device Name / Device Version/ Serial Number) -32-...

  • Page 33: Configuration Tab

    6.2. Configuration tab ① ② ⑤ ④ ③ Fig.6.2 Configuration Tab Table 6.3 Contents of Configuration Tab Item Description Configuration Displays configuration of SI unit. Port setting Displays settings of Port 1(BUS IN) and Port2(BUS OUT). Displays positions of Rotary switches and IP address settings. Rotary switch setting Refer to 3.2 Switch setting...

  • Page 34: Device Status & Diagnostic Tab

    6.3. Device Status & Diagnostic tab ① ② ③ ④ ⑤ ⑥ ⑦ Fig.6.3 Device Status & Diagnostic Tab Table 6.4 Content of Device Status & Diagnostic Tab Item Description Device Status Displays Device Status and Diagnostic of SI unit. &...

  • Page 35: Maintenance Mode

    6.4. Maintenance Mode Forcing outputs, communication settings, and application settings are available in the maintenance mode. 6.4.1. login To enter the maintenance mode, it is necessary to log in. ①Click [LOGIN] tab. ②Enter [Username] and [Password]. ③Click the [SUBMIT] button to log in. ①...
  • Page 36 6.4.2. Network/Application setting ① ③ ② ④ Fig. 6.6 Configuration Tab (Maintenance Mode) Table 6.5 Content of Configuration Tab (Maintenance Mode) Item Description Configuration Displays configuration information of SI unit. Network Enter network settings such as IP address, etc., and click “Network Submit”. Settings *note Device Name...
  • Page 37 ④ ⑤ Fig 6.7 Device Status & Diagnostic tab (Maintenace Mode) Table 6.6 Content of Device Status & Diagnostic Tab (Maintenance Mode) Items Description Device Status Displays Device Status and Diagnostic of SI unit. & Diagnostic Selects a range of output numbers from the drop list corresponding to number of Output range selection manifolds connected in the system.

  • Page 38: Led Display

    7. LED display Status Description Power supply for logic/input is not present or IP address not set. (Not powered, no IP address) Green ON EtherNet/IP connection established. (Connected) Green flashing EtherNet/IP connection not established. (No connections) Red flashing EtherNet/IP connection timeout. (Connection timeout) Red ON Duplicate IP addresses are detected.

  • Page 39: Specification

    8. Specification 8.1. Dimensions Fig.8.1 Dimensions of the SI Unit -39- No. DOC1073641...

  • Page 40: Specifications

    8.2. Specifications Table 8.1 Specifications Item Specification General Dimensions (W x L x H)mm 25.5 x 102.4 x 76.5 Weight 200 g or less Housing materials Protection rating of enclosure IP67 (According to IEC60529) Applicable standard CE/UKCA Marked Withstand voltage 500 VAC、1 min (between FE and all accessible terminals) 10 Mohm or more Insulation resistance...

  • Page 41: Accessories

    9. Accessories 9.1. Accessories for communication connector 9.1.1. Cable with communication connector (SPEEDCON) Part number : PCA-1446566 Item Specification Pin No. Cable colour : Signal Connector M12 Straight (SPEEDCON) Yellow : TD+ Cable length 5000 mm White : RD+ Cable O.D. Φ...
  • Page 42 9.1.3. Cable with communication connector (M12 - RJ45) Part number : EX9-AC 01 0EN-PSRJ Cable length (L) 1000 [mm] 2000 [mm] 3000 [mm] 5000 [mm] 10000 [mm] Item Specification Connector M12 Straight ⇔ RJ45 Cable O.D. Φ 6.4 mm Electric wire cross section 0.14 mm /AWG26 Min.
  • Page 43 9.1.4. Cable with communication connector (M12 - M12, Straight) Part number : EX9-AC 005 EN-PSPS Cable length (L) 500 [mm] 1000 [mm] 2000 [mm] 3000 [mm] 5000 [mm] 10000 [mm] Item Specification Pin No. Cable colour : Signal Connector Yellow : TD+ M12 Straight ⇔...
  • Page 44 9.1.5. Cable with communication connector (M12 - M12, Angle) Part number : EX9-AC 005 EN-PAPA Cable length (L) 500 [mm] 1000 [mm] 2000 [mm] 3000 [mm] 5000 [mm] 10000 [mm] Item Specification Pin No. Cable colour : Signal Connector Yellow : TD+ M12 Angle ⇔...
  • Page 45 9.1.6. Seal cap Part number : EX9-AWTS This cap is used to protect the M12 connector opening when the connector is not used. When a connector is not used, the seal cap can keep the SI Unit under IP65 rated protection. (The one is included with the SI Unit as an accessory.) For M12 connector socket Content...

  • Page 46: Accessories For Power Connector

    9.2. Accessories for power connector 9.2.1. Cable with power supply connector Part number : EX500-AP0 1 0- S Connector specification Straight Angle Cable length (L) 1000 [mm] 5000 [mm] EX500-AP0x0-S EX500-AP0x0-A Item Specification Pin No. Cable colour : Signal Cable O.D. Φ...
  • Page 47 9.2.2. Cable with power supply connector (SPEEDCON) Part number : PCA-140180 4 Cable length(L) 1401804 1500 [mm] 1401805 3000 [mm] 1401806 5000 [mm] Item Specification Pin No. Cable colour : Signal Brown : 24 VDC (For logic/input) M12 Straight Connector (SPEEDCON) White : 24 VDC (For output) Cable O.D.

  • Page 48: Troubleshooting

    10. Troubleshooting The state of the SI Unit is indicated by the LED indication. If a problem occurs on the SI Unit, you can use the following chart to troubleshoot. Also refer to the online diagnostics via the PLC software to help identify the problem. 10.1.

  • Page 49: Troubleshooting Tables

    10.2. Troubleshooting tables Table 10.1 Troubleshooting "MS LED is OFF" State Probable causes Checking methods and measures  Check the power cable wiring. Incorrect power wiring.  Check the pin number and wiring of the power connector, Refer to Section.2.2. MS LED is OFF.
  • Page 50 Table 10.5 Troubleshooting "MS LED is red flashing" State Probable causes Checking methods and measures  Please check with WEB server function or CIP message function to identify output numbers that Short circuit on an output have short-circuit, and check conditions of the outputs.
  • Page 51 Table 10.9 Troubleshooting "NS LED is red flashing" State Probable causes Checking methods and measures  Check the connection of the communication connector and the communication cable. NS LED is red EtherNet/IP connection If disconnected, replace the cable. flashing. timeout. ...
  • Page 52 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. EtherNet/IP is a trademark of ODVA. QuickConnect is a trademark of ODVA.
