7. Specification

7.1. Specifications

Item
General
Protection class
Standards
Dimensions (W x L x H)
Housing material
Weight
Withstand voltage
Insulation resistance
Operating temperature range
Storage temperature range
Operating humidity range
Electrical
Operating voltage
Current consumption
PWR
Under-voltage
detection
Operating voltage *1
PWR(V)
Voltage drop *1
Protection against polarity reversal
Loop through current between
power connectors
Galvanic isolation
Manifold connection
Applicable series
Max. number of valve outputs
Load
Over current protection/detection
Fieldbus
Bus protocol
Version
Communication speed
CoE
FoE
Synchronization Modes
Configuration file
Vendor ID
Product Code
NOTE
*1) SI Unit power supply voltage specification. Supply power according to the solenoid valve used.

Table 7-1. Specifications
IP67 (when fully installed or fitted with protective cover)
(complies with IEC 60529)
CE/UKCA Marking, UL(CSA)
34.2 x 98.7 x 76.5
PBT
200 g
500 VAC 1 min. (between FE and all accessible terminal)
10 MΩ or more (500 VDC between FE and all accessible terminal)
-10 °C to 50 °C
-20 °C to 60 °C
35% to 85% RH (non-condensing)
24 VDC +20%/-15%
150 mA or less (at 24 VDC)
approx. 18 VDC
24 VDC +20%/-15%
1.2 VDC or less (at 24 VDC)
Yes (PWR and PWR(V))
4 A
Yes (between PWR and PWR(V))
JSY 64 station compatible manifold series
128
Solenoid valve with voltage suppressor of 24 VDC, 0.4 W or less (SMC)
Yes (on the valve manifold)
EtherCAT
®
Conformance Test Record V2.3.0
100 Mbps
Supported for parameter setting and diagnostics etc.
Supported
Free Run, SM Synchronous, DC Synchronous
ESI file
0x00000114
0x0100004E
-24-
Specification
No.DOC1041432
