5.5. Configured/Detected Module Ident List (Index 0xF030/0xF050)
Subindex
Name (Slot)
[hex]
0x01 OUT0_7
0x02 OUT8_15
0x03 OUT16_23
0x04 OUT24_31
0x05 OUT32_39
0x06 OUT40_47
0x07 OUT48_55
0x08 OUT56_63
0x09 OUT64_71
0x0A OUT72_79
0x0B OUT80_87
0x0C OUT88_95
0x0D OUT96_103 0x00000000(---) or 0x0002000D
0x0E OUT104_111 0x00000000(---) or 0x0002000E
0x0F OUT112_119 0x00000000(---) or 0x0002000F
0x10 OUT120_127 0x00000000(---) or 0x00020010

5.6. Output count batch reset (Index 0xFB00)

Write value[dec]
Reset all valve output counter values together at once. Refer to
0
0: No output count reset request
1
1: All output count reset request
Table 5-8. Configured/Detected Module Ident List
Set/Read value
[hex]
0x00000000(---) or 0x00020001
0x00000000(---) or 0x00020002
0x00000000(---) or 0x00020003
0x00000000(---) or 0x00020004
0x00000000(---) or 0x00020005
0x00000000(---) or 0x00020006
0x00000000(---) or 0x00020007
0x00000000(---) or 0x00020008
0x00000000(---) or 0x00020009
0x00000000(---) or 0x0002000A
0x00000000(---) or 0x0002000B
0x00000000(---) or 0x0002000C
Table 5-9. Output count batch reset
Indicates whether "8 valves" module is allocated
to each Slot.
0x00000000(---): No allocated
0x00000001...0x00000010:
"8 valves" module is allocated
Configured Module Ident List indicates the
configuration of the slot setting, Detected Module
Ident List indicates the configuration detected by
the SI Unit.
It is recommended that module configuration is
done from Slots, refer to
Description
-21-
Description
Section 3.2.
Section 5.4.
