3. Configuration

3.1. ESI file

To configure the SI Unit with your EtherCAT
Information) file is required. The ESI file contains all necessary information to configure the SI Unit on
your master's software.
The ESI file name is as follows.
 ESI file : SMC_EX260-MECx_V10.xml

3.2. Slot setting

Slot No. Slot name
SLOT0 OUT0_7
SLOT1 OUT8_15
SLOT2 OUT16_23
SLOT3 OUT24_31
SLOT4 OUT32_39
SLOT5 OUT40_47
SLOT6 OUT48_55
SLOT7 OUT56_63
SLOT8 OUT64_71
SLOT9 OUT72_79
SLOT10 OUT80_87
SLOT11 OUT88_95
SLOT12 OUT96_103
SLOT13 OUT104_111 8 valves OUT104_111 0x0002000E
SLOT14 OUT112_119 8 valves OUT112_119 0x0002000F
SLOT15 OUT120_127 8 valves OUT120_127 0x00020010
NOTE
 If the output number assigned to an "8 valves" module is more than the number of valve outputs
connected, the Diagnostic history "Error" occurs and ERR LED blinks (2.5kHz).
In addition, it is not possible to shift to Operational or Safe-Operational status.
(AL Status Code: 0x0070)
master's software, the dedicated ESI (EtherCAT Slave
®
Table 3-1. Slot setting
Module name ModuleIdent
8 valves OUT0_7 0x00020001
8 valves OUT8_15 0x00020002
8 valves OUT16_23 0x00020003
8 valves OUT24_31 0x00020004
8 valves OUT32_39 0x00020005
8 valves OUT40_47 0x00020006
8 valves OUT48_55 0x00020007
8 valves OUT56_63 0x00020008
8 valves OUT64_71 0x00020009
8 valves OUT72_79 0x0002000A
8 valves OUT80_87 0x0002000B
8 valves OUT88_95 0x0002000C
8 valves OUT96_103 0x0002000D
The SI Unit can control up to 16 module sets
with 4 stations/8 points valve outputs.
(total 128 outputs)
The "8 valves" module contains 4 stations/8
points valve outputs as well as 4 stations/8
points diagnostic information.
Set the output No. (Slot No.) to which the "8
valves" module is assigned from the Slots.
The output No. which assigned "8 valves"
module have the process data for diagnostic
information and valve outputs.
Scan the SI Unit for first time configuration to
automatically set the slot to match the actual
valve manifold connected.
When slot setting for increasing or decreasing
the number of valve stations, check the actual
valve manifold connected.
