4. Process data
Input/Output
Index
0x1A00 Valve-coil(s) short circuit diagnosis List OUT0_7
0x1A01 Valve-coil(s) short circuit diagnosis List OUT8_15
0x1A02 Valve-coil(s) short circuit diagnosis List OUT16_23
0x1A03 Valve-coil(s) short circuit diagnosis List OUT24_31
0x1A04 Valve-coil(s) short circuit diagnosis List OUT32_39
0x1A05 Valve-coil(s) short circuit diagnosis List OUT40_47
0x1A06 Valve-coil(s) short circuit diagnosis List OUT48_55
0x1A07 Valve-coil(s) short circuit diagnosis List OUT56_63
Input
0x1A08 Valve-coil(s) short circuit diagnosis List OUT64_71
0x1A09 Valve-coil(s) short circuit diagnosis List OUT72_79
0x1A0A Valve-coil(s) short circuit diagnosis List OUT80_87
0x1A0B Valve-coil(s) short circuit diagnosis List OUT88_95
0x1A0C Valve-coil(s) short circuit diagnosis List OUT96_103
0x1A0D Valve-coil(s) short circuit diagnosis List OUT104_111
0x1A0E Valve-coil(s) short circuit diagnosis List OUT112_119
0x1A0F Valve-coil(s) short circuit diagnosis List OUT120_127
0x1A80 Unit diagnosis List *1
0x1600 Valve output List OUT0_7
0x1601 Valve output List OUT8_15
0x1602 Valve output List OUT16_23
0x1603 Valve output List OUT24_31
0x1604 Valve output List OUT32_39
0x1605 Valve output List OUT40_47
0x1606 Valve output List OUT48_55
0x1607 Valve output List OUT56_63
Output
0x1608 Valve output List OUT65_71
0x1609 Valve output List OUT72_89
0x160A Valve output List OUT80_87
0x160B Valve output List OUT88_95
0x160C Valve output List OUT96_103
0x160D Valve output List OUT104_111
0x160E Valve output List OUT112_119
0x160F Valve output List OUT120_127
NOTE
*1) Unit diagnosis is not included in the process data at the time of initial configuration.
To use it, change the setting of the PDO Assignment (Index 0x1C13) using the configuration
software.
Table 4-1. Overview of process data
Name
-16-
Size
Description
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Refer to
Section 4.1
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0 Refer to
Section 4.1
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Refer to
Section 4.2.1
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
No.DOC1041432
.1.
.
2
.
.
