SMC Networks EX260-MEC1 Operation Manual page 30

State
Valve coil has a short circuit.
The valve manifold is not connected
correctly.
(The SI Unit detected that number
SF LED is red ON.
of valve stations 0 or more than 64.)
The valve station in the manifold
has decreased during operation.
NOTE
 The Diagnosis history
the problem.
State
Incorrect connection at the valve or
Valve is not
the wiring of the valve is broken.
working even
though the LED on
There is a problem other than
the valve is ON.
electrical matter.
The LED on valve
is OFF even Incorrect programming of process
though the output data setting.
instruction is ON.
State
Output count exceeded the limit
value.
SF LED is green
flashing. (0.5 Hz)
The valve station in the manifold
has increased during operation.
Table 9-5. Troubleshooting "SF LED is red ON"
Probable causes
(Section 6.2) allows identification of the output No. or Slot No. that is causing
Table 9-6. Troubleshooting "Valve is not working"
Probable causes
Table 9-7. Troubleshooting "SF LED is green flashing"
Probable causes
Checking methods and measures
 Refer to operation manual of valve and
check/replace the valve.
 Check the number of the valve stations
connected to the SI Unit.
 Tighten the screws with the specified tightening
torque (i.e. 0.6 Nm) and make sure there is no
gap between the SI Unit and the valve manifold.
Restart the SI Unit power supply.
 Check the mounting between the SI Unit, valve
manifold and each valve stations.
Restart the SI Unit power supply.
Checking methods and measures
 Refer to operation manual of valve and
check/replace the valve.
 Refer to operation manual of valve and conduct
maintenance.
 Check the program and output address settings
for the problem area.
Checking methods and measures
 Refer to Diagnosis history
consider replacing the valve corresponding to
the relevant output No..
 Refer to Section
this function.
 Check the mounting between the SI Unit, valve
manifold and each valve stations.
Restart the SI Unit power supply.
-30-
(Section 6.2) and
5.2, Section 5.3, Section 5.4
No.DOC1041432
for
