2. Current transmitter depth below the plane of the locator
At this point, the drill rig operator uses the remote display to drill
to the target.
STEP 5 OF 5
When the horizontal distance is almost the same as the current depth, move
the locator farther out to continue Target Steering.
Depth and distance are accurate until the Locate Line (LL)
passes the locator. Once the FLP reaches the locator, or the
distance is almost the same as the depth, the left/right steering
indicators could be wrong.
Toggle down to turn off Target Steering and return to the Locate Mode
screen.
GLOSSARY DEFINITIONS
*TARGET DEPTH
A value programmed into the locator, so it can be positioned ahead of the transmitter
housing and used as a steering target. The value programmed should be the desired
depth of the transmitter when it reaches the point below the locator. If a locator is
placed above ground level, such as to provide separation from interference, that height
must be added to the target depth.
Note: If using a Falcon Compact Display, only left/right steering information is available.
The locator used with the Falcon Compact Display must still have a target depth set.
This target depth can be any value.
