The locator beeps and
displays a check mark after
a successful calibration.
STEP 6 OF 7
Use the Above Ground Range (AGR) that displays next to check the accuracy
of your calibration. Move the locator to at least two different distances
(including maximum bore depth) and verify distance readings match the
measurement.
STEP 7 OF 7
The locator assumes the transmitter pitch equals zero during
the above ground range check. For accurate readings ensure the
transmitter is approximately level.
Select Exit to return to the
Locate Mode screen, where
you will see clock, pitch, and
signal strength.
Fasten the drill head cover properly before drilling.
