The signal strength increases as you move toward the
transmitter and decreases as you move away from it.
An A near the roll indicator indicates signal Attenuation is in
effect.
STEP 5 OF 12
Move the locator to put the ball in the box.
When the ball is centered in the box, hold the trigger for at least one second
to lock onto the reference signal. The R icon will appear at the top of the
Depth screen. The locate line (LL) will not display later without this reference.
STEP 6 OF 12
Mark this position on the ground as the Front Locate Point (FLP).
STEP 7 OF 12
Hold the trigger to show the
location.
DIGITAL CONTROL, INC
predicted depth *
of the transmitter at this
