STEP 6 OF 6
Click to return to the Main Menu.
TRANSMITTER TEMPERATURE WARNINGS
STEP 1 OF 6
DigiTrak transmitters (Tx), with the exception of DucTrak, have an internal
digital thermometer. The normal below ground temp range is 17° – 40°C. The
Tx temperature displays on the bottom right of the locator screen and
remote display screens.
1. Temperature status icon
2. Temp trend up/down arrows
3. Temperature
DIGITAL CONTROL, INC
DIGITRAK FALCON F2 TOP TOGGLE
USER MANUAL
DCI DigiGuide
05.18.2024
45
