Digital Control F2 DCI DigiGuide User Manual page 48

DIGITRAK FALCON F2 TOP TOGGLE USER MANUAL
DCI DigiGuide 05.18.2024
If used with a Falcon locator without the programmable power mode, the
mode selected while pairing the Tx determines the signal range and the
battery life.
Falcon locators with programmable power mode override any other selection
method when used with a V2 transmitter.
1 FT2L+ V2 is only compatible with Falcon+ locators.
2 For Falcon locators with programmable power mode, Low power also gives
you a faster pitch update rate
3 Range is based on SAE Standard J2520 in AGR mode and Max Mode. Actual
range and battery life will vary based on interference, transmitter housings,
and frequencies.
The battery types listed are the only types recommended for that model and
size. DCI does not recommend using other battery types. *Lithium
Rechargeable (LiR) battery life is based on 21700 battery with 5000 mAh
rating. with a max 4.2 volts. Battery life while asleep is 400 hours for
SuperCell and 200 hours for alkaline. Sleep mode starts 15 minutes after last
roll change.
FTR (Sub-k Rebar) Tx's do not have MultiPower mode and have Standard
power battery life. Depth/data range for Up Band is similar to Standard
power; Down band is similar to Low power mode.
You can see the power mode selected for each band on the Transmitter Info
screen. See " Get Transmitter Info" for steps.
