DIGITRAK FALCON F2 TOP TOGGLE USER MANUAL
DCI DigiGuide 05.18.2024
STEP 1 OF 7
Install the powered-on transmitter in the drill head.
STEP 2 OF 7
From the Main menu, select Calibration.
STEP 3 OF 7
Use 1 PT Cal to calibrate.
STEP 4 OF 7
Using a tape measure, place the near edge of the locator parallel to and
exactly 3 m from the center of the drill head.
STEP 5 OF 7
Click to calibrate the Down band.
