You can also see the Power mode of the current band on the Locate Mode
screen and the TX Info pairing screen.

TRANSMITTER OVERHEAT INDICATOR (TEMP DOT)

DigiTrak transmitters (Tx), with the exception of DucTrak, have temperature
overheat indicators (temp dot) on the front end cap.
1. Black temp dot (voids warranty)
2. Normal white temp dot
The temp dot has an outer yellow ring with a temperature-sensitive 3.15 mm
white dot in the center. If the center temp dot is black, the transmitter has
been exposed to excessive heat and should no longer be used.
