During Drilling
TURN ON HEIGHT-ABOVE-GROUND
STEP 1 OF 2
From the Main menu, select
HAG.
STEP 2 OF 2
If the height shown at the bottom of the screen is acceptable, select Enable
HAG. Otherwise, select Set HAG to enter a new height.
1. Disable HAG
2. Enable HAG
3. Set HAG
The locator must now be held at this height for accurate depth
readings.
HAG must be turned on manually each time after the receiver is
powered on or calibrated.

LOCATING THE TRANSMITTER

STEP 1 OF 12
Find the Rear Locate Point (RLP)
