Mud Ring Installation

1. Using the mud ring as a guide, mark the edges and cut out the material within the marked area.
2. Insert the mud ring into the opening and rotate and secure the locking arms with the supplied screws shown
(see figure 4).
Figure 4. Installing the Mud Ring
3. Follow steps 6 through 9 of
Installation below.

Final Installation

After testing and making any adjustments, perform the following:
1. At the power outlet, unplug the power supply.
NOTE: One power supply can power both the transmitter and compatible receiver (see
and Bottom Panels
2. Mount the transmitter into the wall box or mud ring, and attach the supplied decorator style faceplate to the
figure 3
unit (see
3. At the power outlet, reconnect the power supply. This powers up both units if the compatible receiver is
connected.
Wall
Mud Ring
Site Preparation and Wall Box Installation
on page 7).
on page 5).
starting on page 4, and Final
DTP2 T 201 D • Installation and Operation
Transmitter Rear
6
