DC power input (see
A
2-pole connector (see
connector on a compatible receiver.
Send Power toggle switch — In a DTP2 transmitter to DTP2 receiver configuration, set the toggle switch to
B
the Up (SEND POWER) position on the powered DTP2 unit to enable sending remote power to the far end. Set
the toggle switch to the Down (OFF) position on the DTP2 unit receiving power (see
toggle switch configuration).
ATTENTION:
•
The DTP2 T 201 D device is configured to output power to DTP2 models only. If connected to a
Legacy DTP device, set the toggle switch to the OFF position. Failure to turn the power Off will
damage the connected Legacy DTP device.
•
Le DTP2 T 201 D est configuré pour fournir une alimentation aux modèles DTP2 uniquement. S'il
est connecté à un autre appareil, veuillez positionner l'interrupteur à bascule sur « OFF ». Si
l'interrupteur n'est pas positionné sur Off, vous risquez d'entraîner la défaillance de l'appareil
Legacy DTP connecté.
NOTE: DTP2 transmitters are compatible with Legacy DTP products. However, Remote Power must be
configured properly. Failure to do so will result in damage to the units.
DTP output — Connect one end of the twisted pair cable to the RJ-45 connector on the transmitter (see
C
Connection Details
ATTENTION:
•
Do not connect this device to a telecommunications or computer data network.
•
Ne connectez pas ces appareils à des données informatiques ou à un réseau de
télécommunications.
NOTES:
• When the unit is configured for DTP mode via the rear panel switch, the unit can be powered either
with the included external 12 VDC power supply, or over the DTP2 line by a locally powered
receiver or transmitter. When configured for HDBaseT mode, remote power capability is disabled,
and the unit must be powered locally.
•
When configured for DTP mode, HDMI video, digital embedded audio, and remote power are
available when used with a DTP-compatible receiving device.
•
When configured for HDBaseT mode, HDMI video and digital embedded audio are available when
used with an HDBaseT-compatible receiving device.
Configuration port — Using a USB cable, plug a PC into the transmitter via this bottom panel mini-USB
D
connector for firmware updates.
HDBaseT/DTP toggle switch — Set this 2-position, recessed toggle switch to configure the output between
E
HDBaseT and DTP modes. When configured for HDBaseT, use an HDBaseT-compatible receiver. When
configured for DTP, use a DTP-compatible receiver.
Grounding screw — If the transmitter is not mounted to a grounded metal junction box, Extron recommends
F
connecting the unit to an earth ground using this screw.
figure 6 on page 7) — Plug the included external 12 VDC power supply into either this
Power Supply Wiring
on page 10 to properly wire the RJ-45 connectors).
on page 11 to wire the power connector) or the power input
