Figure 19 Web Interface Operating Status / Diagnostics
1) Voltage Monitor: Monitors the product's voltage. In Standby mode, this section
will be highlighted in red.
2) Current Monitor: Displays the product's current. In Standby mode, the current
will decrease to around 0.2 A.
3) Power Monitor: Displays the product's power consumption. In Standby mode, the
power consumption will decrease to around 5 W.
4) Temperature Monitor: Shows the current operating temperature of the product.
5) RPM: Provides real-time information on the product's current rotation speed.
6) Phase: Provides real-time information on the product's current phase angle.
7) Laser Status: Shows "On" (default) and "Off" states. When Standby mode is
selected, it will display "Off."
8) Star-up Times: Displays the current total number of product startups. It increases
by one each time the power is restarted.
9) Elapsed Time Total T0: Displays the total operating time of the product and the
accumulated working time under various temperatures.
Note:
1)
The page refresh rate is 1 second.
2)
If the voltage/current section turns red, please check if the product is in
Standby mode. If not, check if the product is operating normally.
A.4 Product Firmware Upgrade
Click on the "System" on the web page. This page allows the firmware upgrade for
the mainboard, baseboard, software, web interface, and motor. Follow the steps
below:
1) Contact RoboSense to obtain the upgrade firmware. Once the firmware is ready,
click "Choose File," as shown in Figure 20 .
