2.2.2 Loudspeaker Amplifier Jumpers
See
Figure 2-4
See
Table 2-3
Jumper
JP7
JP8
JP9
Jumper
JP7
JP8
JP9
VoIP Loudspeaker Amplifier Operations Guide
to identify the jumper and component locations.
Figure 2-4. Jumper Locations
and
Table 2-4
for the jumper settings.
Table 2-3. Jumper Settings—Low Power—802.3af Compliant (Default)
Table 2-4. Jumper Settings—High Power—Non-PoE Compliant
930111F
Setting
OFF -> Low Power (21V)
OFF -> Low Power (21V)
Position B -> Low Power
Setting
ON -> High Power (21V)
ON -> High Power (21V)
Position A -> High Power
Installing the VoIP Loudspeaker Amplifier
Loudspeaker Amplifier Setup
JP7
CyberData Corporation
7
JP9
JP8
