CyberData VoIP Loudspeaker Amplifier Part #010859 Operation Manual page 23

3. On the Home Page, review the setup details and navigation buttons described in
Web Page Item
Device Name
Running
Serial #
Ethernet Address
IP Addressing
IP Address
Subnet Mask
Default Gateway
VoIP Loudspeaker Amplifier Operations Guide
Configure the Loudspeaker Amplifier Parameters
Figure 2-12. Home Page
Table 2-8. Home Page Overview
Description
Shows the device name.
Shows the current speaker function.
Device serial number.
Device ethernet address.
Shows the current IP addressing setting (DHCP or static).
Shows the current IP address.
Shows the current subnet mask address.
Shows the current default gateway address.
Link to the Speaker Setup page.
Link to the Network Setup page.
Link to the SIP Setup page.
Link to the MGROUPS Setup page.
930111F
Installing the VoIP Loudspeaker Amplifier
Table
CyberData Corporation
15
2-8.
