- Page 1 VoIP Loudspeaker Amplifier Operations Guide (AC Powered) Part #010859 CyberData Corporation 2555 Garden Road Monterey, CA 93940 (831) 373-2601 930111F...
- Page 2 CyberData Corporation. This manual, and the products, software, firmware, and/or hardware described in this manual are the property of CyberData Corporation, provided under the terms of an agreement between CyberData Corporation and recipient of this manual, and their use is subject to that agreement and its terms.
-
Page 3: Revision History
Revision History Revision CyberData Corporation Date Released Description of Changes 10/31/2006 This is the first release of this manual. 01/18/2007 Adds Section 2.4, "Set up the 4/12/2007 Changes the Authenticate ID and password character limit from 30 to 25 in Table 2-11. -
Page 4: Important Safety Instructions
13. Prior to installation, consult local building and electrical code requirements. GENERAL ALERT GENERAL ALERT CyberData Corporation Warning Electrical Hazard: This product should be installed by a licensed electrician according to all local electrical and building codes. -
Page 5: Hazard Levels
Danger, Warning, and Caution, the specific hazard type, and pictorial alert icons. CyberData Corporation General Alert This pictoral alert indicates a potentially hazardous situation. This alert will be followed by a hazard level heading and more specific information about the hazard. - Page 6 CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 7: Table Of Contents
B.1.1 In a LINUX Environment ...33 B.1.2 In a Windows Environment ...33 Appendix C Troubleshooting/Technical Support C.1 Frequently Asked Questions (FAQ) ...35 C.2 Documentation ...35 C.3 Contact Information ...35 C.4 Warranty ...36 Index VoIP Loudspeaker Amplifier Operations Guide 930111F CyberData Corporation... - Page 8 CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 9: Chapter 1 Product Overview
Create a plan for the locations of your loudspeaker amplifiers. ● Consult local building and electrical code requirements. ● VoIP Loudspeaker Amplifiers—AC Required VoIP Loudspeaker Amplifier Operations Guide Figure 1-1. Public Address System Generic PoE Hub VoIP Phone 930111F Server CyberData Corporation... -
Page 10: Product Features
Product Overview Product Features 1.2 Product Features CyberData Corporation Figure 1-2. Public Address System—Multicast CyberData VoIP Loudspeaker Amplifier Speakers Set in MGROUPS Mode 930111F ● Multicast support ● SIP (RFC 3261) compatible ● Dual-Speed 10/100 Mbps ● Web-based configuration ●... -
Page 11: Supported Protocols
Weight VoIP Loudspeaker Amplifier Operations Guide Specification 96dB/1W/1M S.P. Level 8 W PoE/16 W with internal power supply 10/100 Mbps 802.3af compliant SIP RFC 3261 010859 14” x 10” x 4” 4.4 lbs. 930111F Product Overview Supported Protocols CyberData Corporation... - Page 12 Product Overview Product Specifications CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 13: Chapter 2 Installing The Voip Loudspeaker Amplifier
Quantity Loudspeaker Amplifier Assembly Installation Quick Reference Guide Loudspeaker Amplifier Mounting Accessory Kit (part #070057A) which includes: 3 x #8 x 1-1/4” truss head screws VoIP Loudspeaker Amplifier Operations Guide Table 2-1. Parts List Part Name 930111F Illustration CyberData Corporation... -
Page 14: Loudspeaker Amplifier Setup
Installing the VoIP Loudspeaker Amplifier Loudspeaker Amplifier Setup 2.2 Loudspeaker Amplifier Setup Set up and configure each loudspeaker amplifier before you mount it. CyberData delivers each loudspeaker amplifier with the factory default values indicated in Table 2-2: Parameter IP Addressing... -
Page 15: Loudspeaker Amplifier Jumpers
OFF -> Low Power (21V) Position B -> Low Power Table 2-4. Jumper Settings—High Power—Non-PoE Compliant Setting ON -> High Power (21V) ON -> High Power (21V) Position A -> High Power 930111F Installing the VoIP Loudspeaker Amplifier Loudspeaker Amplifier Setup CyberData Corporation... -
Page 16: Connect The Loudspeaker Amplifier
2.2.3 Connect the Loudspeaker Amplifier Figure 2-5 illustrates how to connect the VoIP Loudspeaker Amplifier (AC-powered) via a Cat 5 Ethernet Connector. Non PoE Hub CyberData Corporation Figure 2-5. Connect a Loudspeaker Cat 5 Ethernet AC Input* Optional 2 Speaker Configuration... -
Page 17: Loudspeaker Type
2.2.3.1 Using the Line Out Output 2.2.3.2 Loudspeaker Type The CyberData VoIP Loudspeaker Amplifier supports an 8 Ohm Bogen or equivalent unamplified loudspeaker. See VoIP Loudspeaker Amplifier Operations Guide for details about connecting the loudspeaker amplifier. - Page 18 You may connect a loudspeaker to a loudspeaker amplifier with a good quality speaker cable that is limited to 25 feet in length. Note Prior to installation, consult local building/electrical code requirements. CyberData Corporation Figure 2-7. Hornspeaker 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 19: Confirm Operation
The Activity LED blinks to indicate network traffic. 930111F Installing the VoIP Loudspeaker Amplifier Loudspeaker Amplifier Setup Power LED (blue/green) Link LED (green/yellow) Status LED (green) Activity LED (green) blue when the power is green for a 10Mb link or CyberData Corporation... -
Page 20: Confirm The Ip Address, Test The Audio, And Check The Volume
Caution Equipment Caution: Pressing and holding the RTFM switch for longer than 20 seconds will restore the loudspeaker amplifier to the factory default settings. See CyberData Corporation (Figure 2-10) on the loudspeaker amplifier face to announce Figure 2-10. RTFM Switch Section 2.6, "Restore the Factory Default Settings"... -
Page 21: Adjust The Volume
2.2.6 Adjust the Volume To adjust the loudspeaker amplifier volume, turn the Volume dial amplifier face. VoIP Loudspeaker Amplifier Operations Guide Installing the VoIP Loudspeaker Amplifier (Figure Figure 2-11. Volume Control 930111F Loudspeaker Amplifier Setup 2-11) on the loudspeaker Volume control CyberData Corporation... -
Page 22: Configure The Loudspeaker Amplifier Parameters
2. When prompted, use the following default Web Access Username and Web Access Password to access the Home Page Web Access Username: admin Web Access Password: admin CyberData Corporation Chapter A, “Mounting the Enclosure” Table 2-7. Factory Default Settings Factory Default Setting static 192.168.3.10... - Page 23 Shows the current subnet mask address. Shows the current default gateway address. Link to the Speaker Setup page. Link to the Network Setup page. Link to the SIP Setup page. Link to the MGROUPS Setup page. 930111F Table 2-8. CyberData Corporation...
- Page 24 Installing the VoIP Loudspeaker Amplifier Configure the Loudspeaker Amplifier Parameters Web Page Item CyberData Corporation Table 2-8. Home Page Overview (continued) Description Link to the Upgrade Firmware web page. 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 25: Configure The Network Parameters
Enter the DNS Server 2 address. Click this button to save your configuration settings. Changing a parameter that has an asterisk next to it will cause a system reboot when saved. 930111F (Figure 2-13). Table 2-9. Table 2-9 . If you select DHCP, CyberData Corporation... - Page 26 4. Connect the speaker to the target network. 5. From a system on the same network as the speaker, open a browser with the new IP address of the speaker. CyberData Corporation Table 2-9. Network Setup Parameters (continued) Description Link to the Speaker Setup page.
-
Page 27: Set Up The Loudspeaker Amplifier
Use this field to change the Web Access Password Use this field to re-enter a new password Enable/Disable the speaker tone (beep) before each page. Enable/Disable the speaker tone (beep) after the system startup. 930111F Installing the VoIP Loudspeaker Amplifier Figure 2-14 CyberData Corporation... -
Page 28: Configure The Sip Parameters
1. Click SIP Setup to open the SIP Setup page For specific server configurations, go to the following URL: Note http://www.CyberData.net/support/voip CyberData Corporation Table 2-10. Loudspeaker Amplifier Setup Parameters (continued) Description Enable/Disable the speaker tone (beep) and audio associated with the RTFM switch. - Page 29 Installing the VoIP Loudspeaker Amplifier Configure the Loudspeaker Amplifier Parameters Figure 2-15. SIP Setup Page VoIP Loudspeaker Amplifier Operations Guide 930111F CyberData Corporation...
- Page 30 SIP Registration* Unregister on Reboot* Register Expiration* 3. After changing the parameters, click Save Settings. CyberData Corporation Table 2-11. SIP Setup Parameters Description Enter the SIP server represented as either a numeric IP address in dotted decimal notation or the fully qualified host name (FQHN) up to 64 characters.
-
Page 31: Set Up The Mgroups
MGROUPS Setup provides the ability to join up to 10 Paging Zones. A Paging Zone can consist of one, or many, CyberData MGROUPS-enabled speakers. There is no limit to how many speakers can be in a given Paging Zone. Each MGROUP is defined by a multicast address and port number. Each MGROUP is also assigned a priority, allowing simultaneously arriving pages to be serviced based on importance. - Page 32 Multicast IP Address Port 2000-65535 Priority MGROUP Name Beep 3. After changing the parameters, click Save Settings. CyberData Corporation Table 2-12. MGROUPS Setup Parameters Description Displays the device name. Use MG-Emergency for the MGROUP with the highest priority. Use MG-(1-8) to assign MGROUPS 1 through 8.
-
Page 33: Upgrade The Firmware And Reboot The Loudspeaker Amplifier
If you do not already have a TFTP server running on your network, see TFTP Server”. 2. Retrieve the latest speaker firmware from the CyberData website: www.CyberData.net/support/voip 3. Unzip the speaker version file. This file may contain the following: •... - Page 34 Table 2-13 Web Page Item System Configuration Bootname Kernel CyberData Corporation Figure 2-17. Firmware Upgrade Page if you are uploading the Kernel and Application files. shows the web page items on the Firmware Upgrade page. Table 2-13. Firmware Upgrade Parameters Description Shows the current configuration.
-
Page 35: Reboot The Loudspeaker Amplifier
Link to go to the SIP Setup page. Link to the MGROUPS Setup page. Link to the Home page. Click on this button to reboot the system. Page". 930111F Installing the VoIP Loudspeaker Amplifier Section 2.3.1, "Log in to the (Figure 2-18). Use the Reboot CyberData Corporation... - Page 36 Installing the VoIP Loudspeaker Amplifier Upgrade the Firmware and Reboot the Loudspeaker Amplifier Figure 2-18. Reboot System Section 2. Click Reboot. A normal restart will occur as per the Status LED section of Table 2-6. CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 37: Restore The Factory Default Settings
VoIP Loudspeaker Amplifier Operations Guide 2-14. The other parameters in the current loudspeaker amplifier configuration Table 2-14. Factory Default Settings Factory Default Setting static 192.168.3.10 admin admin 255.255.255.0 192.168.3.1 930111F Installing the VoIP Loudspeaker Amplifier Restore the Factory Default Settings CyberData Corporation... - Page 38 Installing the VoIP Loudspeaker Amplifier Restore the Factory Default Settings CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 39: Appendix A: Mounting The Enclosure
For mounting, use the three #8 SHEET METAL SCREWS to secure the enclosure. VoIP Loudspeaker Amplifier Operations Guide Table A-15. Table A-15. Wall Mounting Components (Part of the Accessory Kit) Part Name #8 Sheet Metal Screws to mount the enclosure. 930111F Illustration CyberData Corporation... - Page 40 Mount the Enclosure Figure A-1. Loudspeaker Amplifier Enclosure Assembly CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 41: Appendix B: Setting Up A Tftp Server
4. You can find several options online for setting up a Solarwinds server. This example explains how to use the Solarwinds freeware TFTP server, which you can download at: http://www.CyberData.net/support/voip VoIP Loudspeaker Amplifier Operations Guide /tftpboot/ Configure Security tab Transmit Only. 930111F is the path to the directory you created in CyberData Corporation... - Page 42 Set up a TFTP Server CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
-
Page 43: Appendix C: Troubleshooting/Technical
Phone: 831-373-2601, Extension 136 Email: RMA@CyberData.net When returning a product to CyberData, an approved CyberData RMA number must be printed on the outside of the original shipping package. No product will be accepted for return without an approved RMA number. Send the product, in its original package, to the following address:... -
Page 44: Warranty
CyberData warrants its product against defects in material or workmanship for a period of two years from the date of purchase. Should the product fail within the warranty period, CyberData will repair or replace the product free of charge. This warranty includes all parts and labor. -
Page 45: Index
IP settings 14 network 17 SIP 20 using Web interface 14 configuration home page 14 CyberData contact information, corporate, sales, tech support, service 35 default gateway 6, 14, 29 IP address 6, 14, 29 loudspeaker amplifier settings 37... - Page 46 SIP server login 22 login 14 restoring the default 6, 14, 29 port local SIP 22 remote SIP 22 port baud rate 3 CyberData Corporation power LED 11 power requirement 3 power, connecting to loudspeaker amplifier 8 product configuring 14 mounting 31...
- Page 47 6, 14, 29 web configuration log in address 14 web-based loudspeaker amplifier configuration 14 weight 3 Windows, setting up a TFTP server on 33 wiring 1 wiring, electrical code 9, 10 VoIP Loudspeaker Amplifier Operations Guide 930111F CyberData Corporation...
- Page 48 CyberData Corporation 930111F VoIP Loudspeaker Amplifier Operations Guide...
