Summary of Contents for CyberData Part #010861 930106D
- Page 1 VoIP Loudspeaker Amplifier Operations Guide (PoE) Part #010861 930106D...
- Page 2 CyberData Corporation. This manual, and the products, software, firmware, and/or hardware described in this manual are the property of CyberData Corporation, provided under the terms of an agreement between CyberData Corporation and recipient of this manual, and their use is subject to that agreement and its terms.
-
Page 3: Revision History
Revision History Revision CyberData Corporation Date Released Description of Changes 11/06/2006 This is the first release of this manual. 01/16/2007 Adds Section 2.4, "Set up the 4/13/2007 Changes the Authenticate ID and password character limit from 30 to 25 in Table 2-11. - Page 4 CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide...
-
Page 5: Table Of Contents
B.0.1 In a LINUX Environment ...31 B.0.2 In a Windows Environment ...31 Appendix C Troubleshooting/Technical Support C.1 Frequently Asked Questions (FAQ) ...33 C.2 Documentation ...33 C.3 Contact Information ...33 C.4 Warranty ...34 Index VoIP Loudspeaker Amplifier Operations Guide 930106D CyberData Corporation... - Page 6 CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide...
-
Page 7: Chapter 1 Product Overview
Figure 1 illustrates how the VoIP Loudspeaker Amplifier (PoE) is normally installed as part of a public address system. VoIP Loudspeaker Amplifiers—PoE VoIP Loudspeaker Amplifier Operations Guide Figure 1. Public Address System—SIP Generic PoE Hub VoIP Phone 930106D Server CyberData Corporation... -
Page 8: Product Features
Product Overview Product Features 1.2 Product Features CyberData Corporation Figure 2. Public Address System—Multicast CyberData VoIP Loudspeaker Amplifier Speakers Set in MGROUPS Mode 930106D ● Multicast support ● SIP (RFC 3261) compatible ● Dual-Speed 10/100 Mbps ● Web-based configuration ●... -
Page 9: Supported Protocols
Weight VoIP Loudspeaker Amplifier Operations Guide Specification 96dB/1W/1M S.P. Level 8 W PoE/16 W with internal power supply 10/100 Mbps 802.3af compliant SIP RFC 3261 010861 14” x 10” x 4” 4.4 lbs. 930106D Product Overview Supported Protocols CyberData Corporation... - Page 10 Product Overview Product Specifications CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide...
-
Page 11: Chapter 2 Installing The Voip Loudspeaker Amplifier
Quantity Loudspeaker Amplifier Assembly Installation Quick Reference Guide Loudspeaker Amplifier Mounting Accessory Kit (part #070057A) which includes: 3 x #8 x 1-1/4” truss head screws VoIP Loudspeaker Amplifier Operations Guide Table 2-1. Parts List Part Name 930106D Illustration CyberData Corporation... -
Page 12: Loudspeaker Amplifier Setup
Installing the VoIP Loudspeaker Amplifier Loudspeaker Amplifier Setup 2.2 Loudspeaker Amplifier Setup Set up and configure each loudspeaker amplifier before you mount it. CyberData delivers each loudspeaker amplifier with the factory default values indicated in Table 2-2: Parameter IP Addressing... -
Page 13: Loudspeaker Amplifier Jumpers
OFF -> Low Power (21V) Position B -> Low Power Table 2-4. Jumper Settings—High Power—Non-PoE Compliant Setting ON -> High Power (21V) ON -> High Power (21V) Position A -> High Power 930106D Installing the VoIP Loudspeaker Amplifier Loudspeaker Amplifier Setup CyberData Corporation... -
Page 14: Connect The Loudspeaker Amplifier
2.2.3 Connect the Loudspeaker Amplifier Figure 2-3 illustrates how to connect the VoIP Loudspeaker Amplifier (PoE). Figure 2-3. Connect a Loudspeaker Ethernet Hub Optional 2 Speaker Configuration Standard 1 Speaker Configuration 8 Ohms 8 Ohms CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide... -
Page 15: Loudspeaker Type
Ethernet a.Consult a licensed electrician for local electrical code requirements. 2.2.3.1 Loudspeaker Type The CyberData VoIP Loudspeaker Amplifier supports an 8 Ohm Bogen or equivalent unamplified loudspeaker. See 2.2.3.2 Cabling/Wiring You may connect a loudspeaker to a loudspeaker amplifier with a good quality speaker cable that is limited to 25 feet in length. -
Page 16: Confirm Operation
Power Status Link Activity CyberData Corporation Figure 2-5. Loudspeaker Amplifier LEDs—Power and Link Figure 2-6. Loudspeaker Amplifier LEDs—Status and Activity Table 2-6. Loudspeaker Amplifier LEDs Color... -
Page 17: Confirm The Ip Address, Test The Audio, And Check The Volume
Section 2.6, "Restore the Factory Default Settings" settings. See VoIP Loudspeaker Amplifier Operations Guide Installing the VoIP Loudspeaker Amplifier (Figure 2-7) on the loudspeaker amplifier face to announce Figure 2-7. RTFM Switch 930106D Loudspeaker Amplifier Setup RTFM switch CyberData Corporation... -
Page 18: Adjust The Volume
Installing the VoIP Loudspeaker Amplifier Loudspeaker Amplifier Setup 2.2.6 Adjust the Volume To adjust the loudspeaker amplifier volume, turn the Volume dial amplifier face. CyberData Corporation (Figure Figure 2-8. Volume Control 930106D VoIP Loudspeaker Amplifier Operations Guide 2-8) on the loudspeaker... -
Page 19: Configure The Loudspeaker Amplifier Parameters
VoIP Loudspeaker Amplifier Operations Guide Installing the VoIP Loudspeaker Amplifier Configure the Loudspeaker Amplifier Parameters Chapter A, “Mounting the Enclosure” Table 2-7. Factory Default Settings Factory Default Setting static 192.168.3.10 admin admin 255.255.255.0 192.168.3.1 (Figure 2-9): 930106D Table 2-7. CyberData Corporation... - Page 20 Running Serial # Ethernet Address IP Addressing IP Address Subnet Mask Default Gateway CyberData Corporation Figure 2-9. Home Page Table 2-8. Home Page Overview Description Shows the device name. Shows the current speaker function. Device serial number. Device ethernet address.
- Page 21 Installing the VoIP Loudspeaker Amplifier Configure the Loudspeaker Amplifier Parameters Table 2-8. Home Page Overview Web Page Item Description Link to the Upgrade Firmware web page. VoIP Loudspeaker Amplifier Operations Guide 930106D CyberData Corporation...
-
Page 22: Configure The Network Parameters
IP Address* Subnet Mask Default Gateway DNS Server 1* DNS Server 2* CyberData Corporation Figure 2-10. Network Setup Page Table 2-9. Network Setup Parameters Description Select either DHCP IP Addressing or Static IP Addressing by marking the appropriate radio button. If you select Static, configure... - Page 23 Configure the Loudspeaker Amplifier Parameters Table 2-9. Network Setup Parameters Description Link to the Speaker Setup page. Link to the SIP Setup page. Link to the MGROUPS Setup page. Link to the Upgrade Firmware page. Link to the Home page. 930106D CyberData Corporation...
-
Page 24: Set Up The Loudspeaker Amplifier
Change Web Access Username Change Web Access Password Re-enter New Password Speaker Tone Before Paging Speaker Tone After Initialization CyberData Corporation Figure 2-11. Loudspeaker Amplifier Setup Table 2-10. Loudspeaker Amplifier Setup Parameters Description Enter a descriptive name for this device (if desired). -
Page 25: Configure The Sip Parameters
Link to the Network Setup page. Link to the SIP Setup page. Link to the MGROUPS Setup page. Link to the Upgrade Firmware page. Link to the Home Page page. (Figure 930106D Installing the VoIP Loudspeaker Amplifier 2-12). CyberData Corporation... - Page 26 Installing the VoIP Loudspeaker Amplifier Configure the Loudspeaker Amplifier Parameters Figure 2-12. SIP Setup Page CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide...
- Page 27 Link to the Speaker Setup page. Link to the MGROUPS Setup page. Link to the Network Setup page. Link to the Upgrade Firmware page. Link to the Home page. 930106D Table 2-11. CyberData Corporation...
-
Page 28: Set Up The Mgroups
MGROUPS Setup provides the ability to join up to 10 Paging Zones. A Paging Zone can consist of one, or many, CyberData MGROUPS-enabled speakers. There is no limit to how many speakers can be in a given Paging Zone. Each MGROUP is defined by a multicast address and port number. Each MGROUP is also assigned a priority, allowing simultaneously arriving pages to be serviced based on importance. - Page 29 Link to the Network Setup page. Link to the Speaker Setup page. Link to the SIP Setup page. Link to the Upgrade Firmware page. Link to the Home page. 930106D Installing the VoIP Loudspeaker Amplifier Set up the MGROUPS Table 2-12. CyberData Corporation...
-
Page 30: Upgrade The Firmware And Reboot The Loudspeaker Amplifier
If you do not already have a TFTP server running on your network, see TFTP Server”. 2. Retrieve the latest speaker firmware from the CyberData website: www.CyberData.net/support/voip 3. Unzip the speaker version file. This file may contain the following: •... - Page 31 Firmware Upgrade page. Table 2-13. Firmware Upgrade Parameters Description Shows the current configuration. Shows the current boot loader filename. Shows the current kernel filename for partition 1 and 2. 930106D Installing the VoIP Loudspeaker Amplifier CyberData Corporation...
-
Page 32: Reboot The Loudspeaker Amplifier
To reboot a loudspeaker amplifier, log in to the web page as instructed in Configuration Home 1. Click Upgrade Firmware to open the Firmware Upgrade page System section on the right side of the page. CyberData Corporation Table 2-13. Firmware Upgrade Parameters Description Shows the current application filename for partition 1 and 2. - Page 33 Installing the VoIP Loudspeaker Amplifier Upgrade the Firmware and Reboot the Loudspeaker Amplifier Figure 2-15. Reboot System Section 2. Click Reboot. A normal restart will occur as per the Status LED section of Table 2-6. VoIP Loudspeaker Amplifier Operations Guide 930106D CyberData Corporation...
-
Page 34: Restore The Factory Default Settings
Once the settings are restored, a voice message announces the restored default IP address: 192.168.3.10 • A voice message announces that the loudspeaker amplifier is rebooting. • The loudspeaker amplifier reboots. CyberData Corporation Table 2-14. The other parameters in the current loudspeaker amplifier configuration Table 2-14. Factory Default Settings 930106D Factory Default Setting static 192.168.3.10... -
Page 35: Appendix A: Mounting The Enclosure
For mounting, use the three #8 SHEET METAL SCREWS to secure the enclosure. VoIP Loudspeaker Amplifier Operations Guide Table A-15. Table A-15. Wall Mounting Components (Part of the Accessory Kit) Part Name #8 Sheet Metal Screws to mount the enclosure. 930106D Illustration CyberData Corporation... - Page 36 Mount the Enclosure Figure A-1. Loudspeaker Amplifier Enclosure Assembly CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide...
-
Page 37: Appendix B: Setting Up A Tftp Server
4. You can find several options online for setting up a Solarwinds server. This example explains how to use the Solarwinds freeware TFTP server, which you can download at: http://www.CyberData.net/support/voip VoIP Loudspeaker Amplifier Operations Guide /tftpboot/ Configure Security tab Transmit Only. 930106D is the path to the directory you created in CyberData Corporation... - Page 38 Set up a TFTP Server CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide...
-
Page 39: Appendix C: Troubleshooting/Technical
Phone: 831-373-2601, Extension 136 Email: RMA@CyberData.net When returning a product to CyberData, an approved CyberData RMA number must be printed on the outside of the original shipping package. No product will be accepted for return without an approved RMA number. Send the product, in its original package, to the following address:... -
Page 40: Warranty
CyberData warrants its product against defects in material or workmanship for a period of two years from the date of purchase. Should the product fail within the warranty period, CyberData will repair or replace the product free of charge. This warranty includes all parts and labor. -
Page 41: Index
IP settings 13 network 16 SIP 19 using Web interface 13 configuration home page 13 CyberData contact information, corporate, sales, tech support, service 33 default gateway 6, 13, 28 IP address 6, 13, 28 loudspeaker amplifier settings 35... - Page 42 SIP 21 remote SIP 21 port baud rate 3 power LED 10 power requirement 3 power, connecting to loudspeaker amplifier 8 CyberData Corporation product configuring 13 mounting 29 parts list 5 product features 2 product overview product features 2...
- Page 43 6, 13, 28 web access username 6, 13, 28 web configuration log in address 13 web-based loudspeaker amplifier configuration 13 weight 3 Windows, setting up a TFTP server on 31 VoIP Loudspeaker Amplifier Operations Guide 930106D CyberData Corporation...
- Page 44 CyberData Corporation 930106D VoIP Loudspeaker Amplifier Operations Guide...
