Operating Guide | iC7-Hybrid PROFINET
Menu index Parameter
name
10.3.2.2.1 Name of
Station

GSDML File (Device Description File)

4.3
To configure a PROFINET controller, the configuration tool needs a GSDML file for each type of device in the network. The GSDML file is a
PROFINET xml file containing the necessary communication setup data for a device. Each product in the iC7 series has a unique GSDML
file.
Download the GSDML files for the iC7 series from
figuration-files/. Check that the GSDML file version is compatible with the firmware version.

Reference and Main Actual Handling

4.4
For the Grid Converter and DC/DC Converter applications, the Main Reference [REF] and Main Actual Value [MAV] are tied to the DC-link
voltage of the converter. Both of these signals are interfaced as 32-bit floating point values. They are expressed in % of parameter DC-link
Nominal Voltage (parameter number 2834).

Connectivity Settings

4.5
Table 10: General Connectivity Settings for Grid Converter and DC/DC Converter
Menu Parameter
index
2.9.8.1 Fieldbus Fault
Response
2.9.8.2 No Fieldbus
Connection
Response
Danfoss Drives Oy © 2024.04
Parameter Value
number
7080 Accepted characters:
• Lower case letters (a–z)
• Numbers (0–9)
• Special characters: dash (–), full stop (.)
The value can be up to 127 characters or
digits in total. The maximum length for
each component separated by a full stop
or dash is 63 characters or digits. Spaces
are not allowed.
https://www.danfoss.com/en/service-and-support/downloads/dds/fieldbus-con-
Parameter Value
number
1304 • Info (default)
• Warning
• Fault
• Fault, open MCB
See Table 11
the events.
1305 • Info (default)
• Warning
• Fault
• Fault, open MCB
See Table 11
the events.
Description
Select the behavior when a fieldbus fault,
for example loss of I/O connection occurs.
for descriptions of
Select the behavior if an active fieldbus con-
nection has not been established.
for descriptions of
AQ481922002453en-000101 / 172K4283A |
Additional information
Each PROFINET device has
a unique Name of Station.
23
