Operating Guide | iC7-Hybrid PROFINET
Table 10: General Connectivity Settings for Grid Converter and DC/DC Converter (continued)
Menu Parameter
index
2.9.8.3 Process Data
Timeout Response
2.9.8.4 Process Data
Timeout Time
2.9.8.5 Fieldbus Watchdog
Response
2.9.8.6 Fieldbus Watchdog
Delay
2.9.8.7 Fieldbus Watchdog
Start Delay
Table 11: Event Descriptions for Grid Converter and DC/DC Converter
Value
Info
Warning
Fault
Fault, open MCB
24
| Danfoss Drives Oy © 2024.04
Parameter Value
number
1306 • Info (default)
• Warning
• Fault
• Fault, open MCB
See Table 11
the events.
1340 0.05–18000 s
(Default value: 1.00 s)
5244 • No response (default)
• Warning
• Fault
• Fault, open MCB
See Table 11
the events.
5245 0.00–3000 s
(Default: 5.00 s)
5246 0.00–3000 s
(Default: 30.00 s)
Description
The event is logged in the event log.
The converter issues a warning.
A fault is issued, and the modulation is stopped.
A fault is issued, the modulation is stopped and the MCB is opened, if controlled by the converter.
Description
Select the response if there is no fieldbus
connection.
for descriptions of
Set the timeout time. If process data is not
received within the time set, a process data
timeout is triggered.
Select the response in case the fieldbus
watchdog bit (bit 11) has not changed its
value within the specific watchdog delay
time.
for descriptions of
Set a delay time for after which the fieldbus
watchdog event is triggered if the watchdog
bit has not changed its value.
Set a delay time for after which the fieldbus
watchdog event is triggered if the watchdog
bit has not changed its value. This time ap-
plies only immediately after powering the
control unit.
